94
RQT9272
Power supply: AC 220 V to 240 V, 50 Hz
Power consumption: Approx. 33 W
Standby mode: (“Power Save” is set to “On”) Approx. 0.9 W
(“Power Save” is set to “Off”) Approx. 9 W
Recordable discs:
DVD-RAM: 2X SPEED (Ver. 2.0), 2−3X SPEED (Ver. 2.1),
2−5X SPEED (Ver. 2.2)
DVD-R (SL): 1X SPEED (Ver. 2.0), 1−4X SPEED (Ver. 2.0),
1−8X SPEED (Ver. 2.0), 1−16X SPEED (Ver.
2.1)
DVD-R (DL): 2−4X SPEED (Ver. 3.0), 2−8X SPEED (Ver. 3.0)
DVD-RW: 1X SPEED (Ver. 1.1), 1−2X SPEED (Ver. 1.1),
2−4X SPEED (Ver. 1.2), 2−6X SPEED (Ver. 1.2)
+R (SL): 2.4X SPEED (Ver. 1.0), 2.4−4X SPEED (Ver.
1.1), 2.4−8X SPEED (Ver. 1.2), 2.4−16X SPEED
(Ver. 1.3)
+R (DL): 2.4X SPEED (Ver. 1.0), 2.4−8X SPEED (Ver. 1.1)
+RW: 2.4X SPEED (Ver. 1.1), 2.4−4X SPEED (Ver. 1.2)
Recording system:
DVD-RAM: DVD Video Recording format
DVD-R: DVD-Video format
DVD-R DL (Dual Layer):
DVD-Video format
DVD-RW: DVD-Video format
+R
+R DL (Double Layer)
+RW
Recording time:
Max. 8 hours (using 4.7 GB disc)
XP: Approx. 1 hour SP: Approx. 2 hours
LP: Approx. 4 hours
EP: Approx. 6 hours or 8 hours
Maximum Approx. 441 hours with 250 GB HDD (EP 8 hours mode)
XP: Approx. 55 hours, SP: Approx. 110 hours
LP: Approx. 221 hours, EP: Approx. 331 hours/441 hours
Playable discs:
DVD-RAM: DVD Video Recording format
DVD-R:
DVD-Video format, MP3
1
, WMA
1
, JPEG
1
,
DivX
1
DVD-R DL (Dual Layer):
DVD-Video format, MP3
1
, WMA
1
JPEG
1
,
DivX
1
DVD-RW: DVD-Video format, DVD Video Recording format
+R
+R DL (Double Layer)
+RW
DVD-Video, CD-Audio (CD-DA), Video CD, SVCD
2
CD-R/CD-RW: CD-DA
1
, Video CD
1
, SVCD
1,2
, MP3
1
,
WMA
1
, JPEG
1
, DivX
1
Internal HDD capacity:
250 GB
Optical pick-up:
System with 1 lens, 2 integration units
(662 nm wavelength for DVDs, 780 nm wavelength for CDs)
LASER Specifi cation
Class 1 LASER Product
Wave Length: 780 nm (CDs)
662 nm (DVDs)
Laser Power: No hazardous radiation is emitted with the
safety protection
Television system
Tuner System: PAL-I
Channel Coverage: VHF: A to J
UHF: 21 to 69
CATV: 104 MHz to 470 MHz
RF converter output: Not provided
Video
Video system: PAL colour signal, 625 lines, 50 fi elds
NTSC colour signal, 525 lines, 60 fi elds
Recording system: MPEG2 (Hybrid VBR)
Video In (PAL/NTSC):
AV1/AV2 (21 pin), AV3 (pin jack) 1 Vp-p 75 ,
termination
S-Video In (PAL/NTSC):
AV2 (21 pin), AV3 (S terminal) 1 Vp-p 75 ,
termination
RGB In (PAL):
AV2 (21pin) 0.7 Vp-p (PAL) 75 , termination
Video Out (PAL/NTSC):
AV1/AV2 (21 pin), Video Out (pin jack) 1 Vp-p
75 , termination
S-Video Out (PAL/NTSC):
AV1 (21 pin), S-Video Out (S terminal) 1 Vp-p
75 , termination
RGB Out (PAL/NTSC):
AV1 (21 pin), 0.7 Vp-p (PAL) 75 , termination
Component video output (NTSC 480p/480i, PAL 576p/576i)
Y: 1.0 Vp-p 75 , termination
P
B
: 0.7 Vp-p 75 , termination
P
R
: 0.7 Vp-p 75 , termination
Audio
Recording system: Dolby Digital 2 ch, Linear PCM (XP mode)
Audio In: AV1/AV2 (21 pin), AV3 (pin jack)
Input Level: Standard: 0.5 Vrms, Full scale: 2.0 Vrms at
1 kHz
Input Impedance: More than 10 k
Audio Out: AV1/AV2 (21 pin), Audio Out (pin jack)
Output Level: Standard: 0.5 Vrms, Full scale: 2.0 Vrms at
1 kHz
Output Impedance: Less than 1 k
Digital Audio Out: Optical terminal (PCM, Dolby Digital, DTS,
MPEG)
DV Input: IEEE 1394 Standard, 4 Pin :1pc
USB
USB port: TypeA: 1 pc
USB standard: USB 2.0 High Speed
Format: FAT16, FAT32
Video (SD Video)
3
Codec: MPEG 2 (SD-Video Entertainment Video Profi le)
File Format: SD-Video format conforming
HDMI Output: 19 pin type A :1pc
HDMI
TM
(V.1.3a with Deep Colour)
This unit supports “HDAVI Control 4” function.
Quick Start for Recording (Power Save: Off)
1 Sec. Quick Start for Recording
(when connecting to TV using 21-pin Scart, Component Video, Video
or S-Video terminals)
From the power on, recording on, DVD-RAM and HDD starts in
about 1 second after the REC button is pressed. (Quick Start Mode)
Others
Regional Code: # 2
Operating temperature range: 5 C to 40 C
Operating humidity range: 10 % to 80 % RH (no condensation)
Dimensions (W H D): 430 mm 59 mm 286 mm
Mass: Approx. 3.7 kg
1
Finalising is necessary for compatible playback.
2
Conforming to IEC62107
This unit is not compatible with “Chaoji Video CD” available on the
market including CVD, DVCD and SVCD that do not conform to
IEC62107.
3
Video Recording conversion and transfer is possible from USB
to HDD or DVD-RAM disc. After Video Recording conversion and
transfer to HDD or DVD-RAM disc, the playback is possible.
Notes
Specifi cations are subject to change without notice.
Specifi cations
