Panasonic DMR-ES10P

15.3. Tuner P.C.B.
Ref No.
MODE 1234567891011121314151617181920
REC - 0.7 2.8 0.8 2.4 2.4 4.5 - 2.5 2.5 - - - 2.7 2.3 - 0 0 - -
PLAY - 0.7 2.8 0.8 2.4 2.4 4.5 - 2.5 2.5 - - - 2.7 2.3 - 0 0 - -
STOP - 0.7 2.9 0.8 2.4 0 4.4 - 0 0 - - - 0 0 - 0 0 - -
Ref No.
MODE 21 22 23 24 25 26 27 28 29 30 31 32
REC 0 0 2.2 5.1 0 0 5.1 0 2.2 2.2 - 2.3
PLAY 0 0 2.2 5.1 0 0 5.1 0 2.2 2.2 - 2.3
STOP 0000000000-0
Ref No.
MODE E C B
REC 0 0 0
PLAY 0 0 0
STOP 0 0 0
IC7801
IC7801
Q7801
15.4. P9001 Connector
Ref No.
MODE 1234567891011121314151617181920
REC 5.1 5.1 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.1 3.3 2.3 - 5.1 - - -
PLAY 5.1 5.1 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.1 3.3 2.3 - 5.1 - - -
STOP 5.1 5.1 3.3 3.3 3.3 3.3 3.3 3.2 3.3 0.2 3.3 3.2 3.2 3.3 2.3 - 5.1 - - -
Ref No.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
REC ----0-03.32.54.82.5-0001.703.32.5-
PLAY ----0-03.32.54.82.5-0001.703.32.5-
STOP ----0-03.32.54.82.5-0001.703.32.5-
Ref No.
MODE 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
REC 2.53.300001.15.00-1.55.003.31.03.703.71.16.2
PLAY 2.53.300001.15.00 -1.55.003.31.03.703.71.16.2
STOP2.53.300001.15.00-1.55.003.31.03.703.71.16.2
Ref No.
MODE 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
REC 0 6.2 1.0 6.2 0 3.3 0 3.3 0 3.3 0 3.3 0 3.3 0 - 0 - 0 -
PLAY 0 6.2 1.0 6.2 0 3.3 0 3.3 0 3.3 0 3.3 0 3.3 0 - 0 - 0 -
STOP 0 6.2 1.0 6.2 0 3.3 0 3.3 0 3.3 0 3.3 0 3.3 0 - 0 - 0 -
Ref No.
MODE 81 82 83 84 85 86 87 88
REC 0 1.5 1.3 1.5 0 1.5 2.1 1.5
PLAY 0 1.5 1.3 1.5 0 1.5 2.1 1.5
STOP 0 1.5 1.3 1.5 0 1.5 2.1 1.5
P9001
P9001
P9001
P9001
P9001
30
DMR-ES10P / DMR-ES10PC
