Panasonic DMR-ES10P

Notes:
*Important safety notice:
Components identified by
mark have special
characteristics important for safety.
Furthermore, special parts which have purposes of fire-
retardant (resistors), high-quality sound (capacitors), low-
noise (resistors), etc. are used.
When replacing any of components, be sure to use only
manufactures specified parts shown in the parts list.
*Warning: This product uses a laser diode. Refer to caution
statements.
*Capacity values are in microfarads (µF) unless specified
otherwise, P=Pico-farads (pF), F=Farads (F).
*Resistance values are in ohms, unless specified otherwise,
1K=1,000 (OHM), 1M=1,000k (OHM).
*The marking (RTL) indicates the retention time is limited
for this item. After the discontinuation of this assembly in
production, it will no longer be available.
*“<IA>-<IB>”, marks in Remarks indicate languages of
instruction manuals. [<IA>: Canadian French, <IB>: English
French]
*All parts except parts mentioned [SPC] in the Remarks
column are supplied from PAVCSG.
*Parts mentioned [SPC] are supplied from PAVC
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
n
01 CASING/ACCESSORY/P
ACKING
1 VEP70115A FRONT(L) P.C.B. (RTL)
2 VEP79111B MAIN P.C.B. 1 (RTL)
2-1 VEP07A76B TUNER P.C.B. 1 (RTL)
3 VEP79104A DIGITAL P.C.B. 1 (RTL)(P)
3 RFKBES10PC DIGITAL P.C.B. 1 (RTL)(PC)
4 VEP71105A POWER SUPPLY
P.C.B.
1 (RTL)
5 RGR0354B-A REAR PANEL 1 (P)
5 RGR0354B-B REAR PANEL 1 (PC)
6 RKA0166-T FOOT RUBBER 4
7 VEE1A60 WIRE WITH
CONNECTOR(4P)
1
8 VEE1B41 WIRE WITH
CONNECTOR(2P)
1
9 VWJ1775 FFC(40P) 1
10 RHD30115 SCREW 3
11 RHD30119-S SCREW 10
12 RYP1268A-S FRONT PANEL ASS’Y1 1 (P-S)(PC)
12 RYP1268A-K FRONT PANEL ASS’Y1 1 (P-K)
12-1 RKF0728-K TRAY DOOR 1
12-2 VMB3410 TRAY SPRING 1
12-3 RMR1698-S SHAFT HOLDER 1
12-4 RGK1885-S REC BUTTON RING 1
12-5 RGK1886-Q FL ORNAMENT 1
12-6 RKF0729A-S PANEL DOOR 1 (P-S)(PC)
12-6 RKF0729A-K PANEL DOOR 1 (P-K)
12-7 RHD26045 SCREW 1
13 RMA1909 DIGITAL ANGLE 1
14 RMA1913 POWER P.C.B. ANGLE 1
15 XSN3+4FJ SCREW 1
16 RHDX30005 SCREW 14
17 RHD30113 SCREW 2 (P-S)(PC)
17 RHD30113-1K SCREW 2 (P-K)
18 RKM0532-S TOP CASE 1 (P-S)(PC)
18 RKM0532-K TOP CASE 1 (P-K)
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
20 RFKNVXY1867 RAM DRIVE UNIT 1 (RTL)(SPC)
21 RMV0302 BARRIER 1 (SPC)
22 RMX0323 PCB SPACER 2
23 RMX0298 PCB SPACER 1
24 RXQ1325 FRONT ANGLE 1
A1 N2QAKB000055 REMOTE CONTROL
ASS’Y
1
A1-1 BNL11M201B BATTERY COVER 1
A2 K2CB2CB00006 AC CORD 1
A3 K2KA6CA00001 AV CORD 1
A4 K2KZ2BA00001 RF COAXIAL CABLE 1
A5 RPQF0220 ACCESSORY CASE 1
A6 RPFX0067 POLYETHYLENE
BAG(F.B.)
1
A7 RQCA1004 DISC CAUTION SHEET 1
A8 RQCB0833 CCP SHEET 1
A9 RQT8010-C OPERATING
INSTRUCTIONS
1 <IA>(PC)
A9 RQT8009-P OPERATING
INSTRUCTIONS
1 <IB>
A10 RQCC2431 DVD MEDIA SHEET 1
F1101 K5D162BK0005 FUSE 1
PC1 RPG7504 PACKING CASE 1 (P-S)
PC1 RPG7603 PACKING CASE 1 (P-K)
PC1 RPG7505 PACKING CASE 1 (PC)
PC2 RPN1790 CUSHION 1
PC4 VPF0505 POLYETHYLENE
BAG(UNIT)
1
n
02 VEP79111B (MAIN P.C.B.)
B7501 N4BCT50A0005 BATTERY 1
C1503 F2A1A2210063 10V 220U 1
C1504 F2A1E1010067 25V 100U 1
C1505 F1J0J106A014 6.3V 10U 1
C1507 F2A1A101A389 10V 100U 1
C1508 ECJ1VB1H103K 50V 0.01U 1
C1509 ECJ1VB0J105K 6.3V 1U 1
C1510 ECJ1VB1A105K 10V 1U 1
C1511,1
2
ECJ1VB0J105K 6.3V 1U 2
C1515,1
6
F2A1A470A388 10V 47U 2
C1517 ECJ1VC1H331J 50V 330 1
C1518 F2A1A101A389 10V 100U 1
C1526 F2A1A470A388 10V 47U 1
C1535 ECJ1VB1A105K 10V 1U 1
C1536 ECJ1VB0J105K 6.3V 1U 1
C1538 ECJ1VB1A105K 10V 1U 1
C1539 ECJ1VB0J105K 6.3V 1U 1
C1540 ECJ1VB1H103K 50V 0.01U 1
C1544 ECJ1VB1H103K 50V 0.01U 1
C1551 ECJ1VB1H103K 50V 0.01U 1
C1552 ECJ1VB1A105K 10V 1U 1
C1553 ECJ1VB0J105K 6.3V 1U 1
C3001 ECJ1VC1H561J 50V 560P 1
C3005 ECJ1VB1C333K 16V 0.033U 1
C3006-
08
ECJ1VB1C104K 16V 0.1U 3
C3010-
17
ECJ1VB1H103K 50V 0.01U 8
C3018 F2A0J470A245 6.3V 47U 1
C3019-
21
ECJ1VB1H103K 50V 0.01U 3
C3022 F2A0J471A247 6.3V 470U 1
C3023 F2A0J470A245 6.3V 47U 1
C3024 F2A0J331A247 6.3V 330U 1
C3026 F2A0J331A247 6.3V 330U 1
21 Replacement Parts List
61
DMR-ES10P / DMR-ES10PC
