Panasonic DMR-ES10P

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
K7502-
05
ERJ3GEY0R00V 1/10W 0 4
K7509 ERJ3GEY0R00V 1/10W 0 1
K7511 ERJ3GEY0R00V 1/10W 0 1
K7513,1
4
ERJ3GEY0R00V 1/10W 0 2
K7516-
18
ERJ3GEY0R00V 1/10W 0 3
L1501 G0A220GA0026 COIL 22UH 1
L3001,0
2
ELEXT220JBV COIL 22UH 2
L4901 ELESN220KA COIL 22UH 1
L7502 ELESN390JA COIL 39UH 1
L7505 G0C220JA0019 COIL 22UH 1
LB1503-
06
J0JKB0000003 COIL 4
LB3905-
10
J0JCC0000103 COIL 6
LB3915 J0JCC0000103 COIL 1
LB3917,
18
J0JCC0000103 COIL 2
LB3924-
29
J0JCC0000103 COIL 6
LB4903-
07
J0JCC0000103 COIL 5
LB4909 J0JCC0000103 COIL 1
LB4911,
12
J0JCC0000103 COIL 2
LB7402,
03
J0JKB0000003 COIL 2
LB7409,
10
J0JHC0000032 COIL 2
LB7411,
12
ERJ3GEY0R00V 1/10W 0 2
LB7501-
03
ERJ3GEY0R00V 1/10W 0 3
LB7504 J0JCC0000060 COIL 1
LB7506-
08
ERJ3GEY0R00V 1/10W 0 3
P1501 K1KA23A00003 CONNECTOR(23P) 1
P1502 K1KA04A00196 CONNECTOR(4P) 1
P7401 K1KA88A00002 CONNECTOR(88P) 1
P7505 K1KA03A00173 CONNECTOR(3P) 1
PP7404 K1KA13A00041 CONNECTOR(MALE)
13P
1
Q4001 2SB1218A0L TRANSISTOR 1
Q4002,0
3
2SD132800L TRANSISTOR 2
Q7503 2SB0709A0L TRANSISTOR 1
Q7504 2SD1819A0L TRANSISTOR 1
Q7506 2SD132800L TRANSISTOR 1
Q7507 2SD1994BR1VT TRANSISTOR 1
Q7508 2SD0601A0L TRANSISTOR 1
QR4001-
04
UNR521100L TRANSISTOR 4
QR7502 UNR511300L TRANSISTOR 1
QR7503 UNR521200L TRANSISTOR 1
R1503 ERJ3GEYJ332V 1/10W 3.3K 1
R1504 ERJ3GEYJ101V 1/10W 100 1
R1506 ERJ3RBD103V 1/16W 10K 1
R1507 ERJ3RBD821V 1/16W 820 1
R1508 ERJ3RBD182V 1/16W 1.8K 1
R1511-
13
ERDS2TJ271T 1/4W 270 3
R1523 ERJ3GEYJ822V 1/10W 8.2K 1
R3025 ERJ3RBD153V 1/16W 15K 1
R3026 ERJ3GEYJ105V 1/10W 1M 1
R3028 ERJ3GEYJ471V 1/10W 470 1
R3030 ERJ3GEYJ750V 1/10W 75 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
R3032,3
3
ERJ3GEYJ103V 1/10W 10K 2
R3036 ERJ3GEYJ103V 1/10W 10K 1
R3039,4
0
ERJ3GEYJ221V 1/10W 220 2
R3041 ERJ3RBD104V 1/16W 100K 1
R3901,0
2
ERJ3GEYJ750V 1/10W 75 2
R3903 ERJ3GEYJ102V 1/10W 1K 1
R3904,0
5
ERJ3GEYJ750V 1/10W 75 2
R3906 ERJ3GEYJ102V 1/10W 1K 1
R3907-
09
ERJ3GEYJ750V 1/10W 75 3
R3911,1
2
ERJ3GEYJ750V 1/10W 75 2
R3915 ERJ3GEYJ912V 1/10W 9.1K 1
R3923-
25
ERJ3GEYJ750V 1/10W 75 3
R3926 ERJ3GEYJ102V 1/10W 1K 1
R3927-
29
ERJ3GEYJ750V 1/10W 75 3
R4001-
04
ERJ3GEYJ104V 1/10W 100K 4
R4010 ERJ3GEY0R00V 1/10W 0 1
R4011-
14
ERJ6GEYJ102V 1/8W 1K 4
R4015,1
6
ERJ3GEYJ104V 1/10W 100K 2
R4024,2
5
ERJ3GEYJ101V 1/10W 100 2
R4026 ERJ3RBD153V 1/16W 15K 1
R4027 ERJ3RBD103V 1/16W 10K 1
R4028 ERJ3RBD153V 1/16W 15K 1
R4029 ERJ3RBD103V 1/16W 10K 1
R4031,3
2
ERJ6GEYJ102V 1/8W 1K 2
R4037,3
8
ERJ3GEYJ104V 1/10W 100K 2
R4043,4
4
ERJ3RBD392V 1/16W 3.9K 2
R4045,4
6
ERJ3RBD622V 1/16W 6.2K 2
R4049-
52
ERJ3GEYJ103V 1/10W 10K 4
R4059,6
0
ERJ3GEYJ473V 1/10W 47K 2
R4061 ERJ3GEYJ681V 1/10W 680 1
R4063,6
4
ERJ3GEYJ272V 1/10W 2.7K 2
R4066 ERJ3GEYJ681V 1/10W 680 1
R4069 ERJ3GEYJ221V 1/10W 220 1
R4072 ERJ3GEYJ221V 1/10W 220 1
R4901 ERJ3GEY0R00V 1/10W 0 1
R4903 ERJ3GEY0R00V 1/10W 0 1
R7401 ERJ3GEY0R00V 1/10W 0 1
R7402,0
3
ERJ3GEYJ472V 1/10W 4.7K 2
R7442 ERJ3RBD222V 1/16W 2.2K 1
R7443 ERJ3RBD102V 1/16W 1K 1
R7444 ERJ3RBD153V 1/16W 15K 1
R7445 ERJ3RBD222V 1/16W 2.2K 1
R7446 ERJ3RBD133V 1/16W 13K 1
R7503 ERJ3GEYJ102V 1/10W 1K 1
R7504 ERJ3GEYJ103V 1/10W 10K 1
R7505 ERJ3GEYG153V 1/10W 15K 1
R7506 ERJ3GEYG152V 1/10W 1.5K 1
R7507 ERJ3GEYG562V 1/10W 5.6K 1
R7508 ERJ3GEY0R00V 1/10W 0 1
R7510 ERJ3RBD273V 1/16W 27K 1
R7515 ERJ3GEYJ103V 1/10W 10K 1
R7516 ERJ3GEYJ473V 1/10W 47K 1
R7517,1
8
ERJ3GEYJ101V 1/10W 100 2
R7519-
21
ERJ3RBD822V 1/16W 8.2K 3
63
DMR-ES10P / DMR-ES10PC
