Panasonic DMR-ES10P

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
W513-15 ERJ6GEY0R00V 1/8W 0 3
W516 ERJ3GEY0R00V 1/10W 0 1
W517,18 ERJ6GEY0R00V 1/8W 0 2
W519 ERJ3GEY0R00V 1/10W 0 1
W520 ERJ6GEY0R00V 1/8W 0 1
W521 ERJ3GEY0R00V 1/10W 0 1
n
05 VEP71105A (POWER SUPPLY
P.C.B.)
C1120 ECQU2A104MLC 250V 0.1U 1
C1121 ECQU2A103MLA 250V 0.01U 1
C1122-
24
ECKWNA102MEV 250V 1000P 3
C1143 EEUED2V101E 350V 100U 1
C1150 F2A1V5600013 35V 56U 1
C1151 F1B3A182A009 250V 1800P 1
C1152 ECJ2VC1H101J 50V 100U 1
C1153 ECJ2VB1H222K 50V 2200P 1
C1154 ECJ2VB1H102K 50V 1000P 1
C1200 ECQV1H224JL3 50V 0.22U 1
C1201 ECJ2VB1E473K 25V 0.047U 1
C1202 ECJ2VB1E104K 25V 0.1U 1
C1260 F2A1A821A540 10V 820U 1
C1262 F2A1A2210063 10V 220U 1
C1270 F2A1C681A624 16V 680U 1
C1272,7
3
EEUFM1E221B 25V 220U 2
C1274 ECJ2VB1E104K 25V 0.1U 1
C1302 F2A1A2210063 10V 220U 1
C1303 ECJ2VB1E104K 25V 0.1U 1
C1401 EEUFM1E221B 25V 220U 1
C1402-
04
ECJ2VB1E104K 25V 0.1U 3
C1405 ECJ2VC1H270J 50V 27P 1
C1406 ECJ2VB1E104K 25V 0.1U 1
C1407 EEUFM1E221B 25V 220U 1
C1408,0
9
ECJ2VB1E104K 25V 0.1U 2
C1410 ECJ2VB1E473K 25V 0.047U 1
C1411 ECJ2VC1H270J 50V 27P 1
C1412 ECJ2VB1E104K 25V 0.1U 1
C1413 F2A1A681A540 10V 680U 1
C1414 ECJ2VB1E104K 25V 0.1U 1
C1415 F2A1A681A540 10V 680U 1
C1417,1
8
F1J0J106A014 6.3V 10U 2
C1421 ECJ2VB1E104K 25V 0.1U 1
D1140 B0EDKT000009 DIODE 1
D1151 B0HAGM000006 DIODE 1
D1152 MAZ80910ML DIODE 1
D1153 MAZ4270NMF DIODE 1
D1155 MAZ73000BC DIODE 1
D1156 MA2J11100L DIODE 1
D1201 B0JAQE000004 DIODE 1
D1261 B0JAQE000004 DIODE 1
D1271 B0JAQG000005 DIODE 1
D1305 B0JCPE000015 DIODE 1
D1401,0
2
B0JCPE000015 DIODE 2
IC1150 C0DACZH00022 IC 1
IC1200 C0DAEMB00003 IC 1
IC1270 C0DAZJH00003 IC 1
IC1302 C0CBCYG00004 IC 1
IC1401,
02
C0DBAKG00007 IC 2
IP1402 K5H3022A0013 IC PROTECTOR 1
L1120 G0B100E00002 COIL 10UH 1
L1260 G0A100HA0023 COIL 10UH 1
L1270 G0A100HA0023 COIL 10UH 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
L1400 G0A220GA0026 COIL 22UH 1
L1401,0
2
G0A220ZA0041 COIL 22UH 2
L1403 G0A220GA0026 COIL 22UH 1
LB1122,
23
J0JKB0000003 COIL 2
LB1126 J0JHC0000012 COIL 1
LB1130,
31
J0JKB0000003 COIL 2
LB1400,
01
J0JHC0000012 COIL 2
P1101 K2AB2H000004 AC INLET 1
P1102 K1KB23A00002 CONNECTOR(FEMALE)
23P
1
Q1200 B3PBA0000078 TRANSISTOR 1
Q1400,0
1
B1DHDD000022 TRANSISTOR 2
QR1300 UNR221300L TRANSISTOR 1
QR1302-
04
UNR221300L TRANSISTOR 3
QR1307,
08
UNR221300L TRANSISTOR 2
R1120 ERDS1TJ474B 1/4W 0.47K 1
R1150 ERDS2TJ6R8T 1/4W 6.8 1
R1151 ERDS2TJ562T 1/4W 5.6K 1
R1152 ERDS2TJ103T 1/4W 10K 1
R1154 ERJ6RBD562V 1/10W 5.6K 1
R1155 ERJ6GEY0R00V 1/8W 0 1
R1156 ERJ6GEYG183V 1/8W 18K 1
R1157 ERJ6RBD681V 1/10W 680 1
R1200 ERJ6GEYG393V 1/8W 39K 1
R1201 ERJ6GEY0R00V 1/8W 0 1
R1204 ERJ6GEYG472V 1/8W 4.7K 1
R1205 ERJ6GEYG473V 1/8W 47K 1
R1206 ERJ6GEYG242V 1/8W 2.4K 1
R1207 ERDS2TJ103T 1/4W 10K 1
R1208 ERJ6GEYG241V 1/8W 240 1
R1209 ERJ6GEYJ102V 1/8W 1K 1
R1210 ERJ6GEYG362V 1/8W 3.6K 1
R1270 ERDS2TJ472T 1/4W 4.7K 1
R1301 ERJ6RBD182V 1/10W 1.8K 1
R1302 ERJ6RED820V 1/10W 82 1
R1303 ERJ6RBD202V 1/10W 2K 1
R1305 ERJ6GEYJ472V 1/8W 4.7K 1
R1309 ERDS2TJ103T 1/4W 10K 1
R1310 ERJ6GEY0R00V 1/8W 0 1
R1313 ERJ6GEYJ103V 1/8W 10K 1
R1401 ERJ6GEYJ333V 1/8W 33K 1
R1402 D1BFR047A010 47 1
R1403 ERJ6RBD202V 1/10W 2K 1
R1404 ERJ6RBD203V 1/10W 20K 1
R1405 ERJ6GEYJ333V 1/8W 33K 1
R1406 D1BFR068A007 0.068 1
R1407 ERJ6RBD471V 1/10W 470 1
R1408,0
9
ERJ6RBD562V 1/10W 5.6K 2
R1411 ERJ6RBD512V 1/10W 5.1K 1
T1150 ETS28AZ1H5AD TRANSFORMER 1
VA1110 ERZV10D471CS V.R. 1
ZA1103,
04
EYF52BCY FUSE HOLDER 2
n
06 VEP70115A (FRONT(L)
P.C.B.)
P7001 K1KA03A00173 CONNECTOR(3P) 1
65
DMR-ES10P / DMR-ES10PC
