Panasonic DMR-ES30VEG

Service Mode
Number
Contents Contents of Indication on minute Contents of Indication on second Remarks
7 Manual mechanism
operation
Mechanism position (Real time) Ordering for the Motors Press the following key;
PLAY key: Loading
STOP key: Unloading
0L: EJECT position
02: DOWN position
03: RREW position
04: LOAD position
05: REV position
06: PLAY position
07: POFF position
08: STOP_R position
09: STOP_F position
0- : FF/REW position
0 _: Intermediate between each
positions
0*, 2*: CYL off,
CAP off
1*:CYL off,
CAP on (fwd)
3*: CYL off,
CAPon (rev)
8*, A*: CYL on,
CAP off
9*: CYL on,
CAPon (fwd)
B*: CYL on,
CAP on (rev)
*0: Motor off
*1:Loading
*2: Unloading
*3: Break (Load + Unload)
27
DMR-ES30VEG / DMR-ES30VEC / DMR-ES30VEB
