NOTES:
*Important safety notice:
Components identified by
mark have special
characteristics import ant for safety.
Furthermore, special parts which have purposes of
fire-retardant (resistors), high-quality sound (capacitors),
low-noise (resistors), etc. are used.
When replacing any of components, be sure to use
only manufactures specified parts shown in the parts list.
*Warning: This product uses a laser diode.
Refer to caution statements.
*Capacity values are in microfarads (µF) unless
specified otherwise, P=Pico-farads (pF), F=Farads (F).
*Resistance values are in ohms, unless specified otherwise,
1K=1,000 (OHM), 1M=1,000k (OHM).
*The marking (RTL) indicates the retention time is
limited for this item. After the discontinuation of this
assembly in production, it will no longer be available.
*Printed Circuit Board’s are identified by “n” character.
*All parts except parts mentioned [SPC] in the Remarks
column are supplied from PAVCG.
*Parts mentioned [SPC] are supplied from PAVC.
The *1, *2, *3 in the Remarks column shows the models
as follows:
*1 = DMR-ES30VEB
*2 = DMR-ES30VEC
*3 = DMR-ES30VEG
No indication = all models
27.1. VHS MECHANISM PARTS
Ref.
No.
Part No. Part Name &
Description
PCS Remarks
1 VEG1648-DT RDD CYLINDER 1
2 VEM0750 CAPSTAN UNIT 1
3 L1AZ00000004 FE HEAD UNIT 1
4 VDG1510 INTERMEDIATE GEAR 1
5 VDG1511-4 MAIN CAM GEAR 1
6 VDG1512 IDLER GEAR 1
7 VDG1512 IDLER GEAR 1
8 VDG1514-1 CHANGE GEAR 1
9 VDR0372 REEL TABLE 1
10 VDR0372 REEL TABLE 1
11 VDV0391-2 CAPSTAN BELT 1
12 VMB3550 CHANGE GEAR SPRING 1
14 VMD4252 OPENER PIECE 1
15 VMD4253 LED PRISM 1
17 VML3624-1 MAIN LEVER 1
18 VML3626-1 PINCH CHARGE ARM 1
19 VML3632 IDLER ARM 1
20 VMX3092 P4 CAP 1
21 VDB1431 TENSION ARM BOSH 1
22 VEM0796 LOADING MOTOR UNIT 1
23 VDG1637 WORM GEAR 1
24 VMD4987 WORM BEARING 1
25 VXA7105-2 SUPPLY SHAFT HOLDER UNIT 1
26 VXA7106-2 TAKE UP SHAFT HOLDER UNIT 1
27 L1AE00000036 AC HEAD UNIT 1
28 VXA7311 SECTOR GEAR UNIT 1
29 VXL3107 SUPPLY LOADING ARM UNIT 1
Ref.
No.
Part No. Part Name &
Description
PCS Remarks
30 VXL3108 TAKE UP LOADING ARM UNIT 1
31 VXL3109-4 PINCH ARM UNIT 1
32 VXL3110 P5 ARM UNIT 1
33 VXL3111-1 TENSION ARM UNIT 1
34 VMB3547-3 TENSION SPRING 1
35 VXL3112 SUPPLY BRAKE ARM UNIT 1
36 VXL3113 TAKE UP BRAKE ARM UNIT 1
37 VMB3548-2 TAKE UP BRAKE SPRING 1
38 VXL3124-2 CHANGE LEVER UNIT 1
39 VXP2133-1 CENTRE CLUTCH UNIT 1
40 VXP2168 TORQUE CLUTCH UNIT 1
41 VMD4983 FPC HOLDER 1
50 VMA0L25 TOP PLATE 1
51 VMD4255-4 SIDE PLATE (L) UNIT 1
52 VMD4254-4 SIDE PLATE (R) UNIT 1
53 VML3706-1 OPENER LEVER 1
54 VXA7110-3 CASSETTE HOLDER UNIT 1
55 VXL3160 MAIN SHAFT UNIT 1
B1 VHD1044 SCREW 1
B2 XSN3+35 SCREW 1
B3 XTN26+7J SCREW 1
B4 XTN26+7J SCREW 1
B5 XTN26+7J SCREW 1
B6 XTV26+5F SCREW 1
B7 XTV26+5F SCREW 1
B8 XTV26+8FR SCREW 1
B9 XTV26+8FR SCREW 1
B10 VHD1066 SCREW 1
B11 VHD1066 SCREW 1
B12 VHD1185 SCREW 1
B13 VHD1095-1 SCREW 1
B14 VHD1117-1 SCREW 1
B15 VHD1117-1 SCREW 1
W1 VMX2208 WASHER 1
W2 VMX3196 WASHER 1
W3 VMX2699 WASHER 1
W4 VMX3196 WASHER 1
27.2. MECHANISM & CASING
PARTS
Ref.
No.
Part No. Part Name &
Decription
PCS Remarks
1 VXY1867 RAM DRIVE UNIT 1
[SPC]
2 n VEP06F87B MAIN P.C.B. 1 1* RTL
2 n VEP06F87E MAIN P.C.B. 1 2* RTL
2 n VEP06F87A MAIN P.C.B. 1 3* RTL
3 n VEP09137A POWER DIGITAL
INTERFACE P.C.B.
1 RTL
4 n RFKBES30VEB DIGITAL P.C.B. 1 1* RTL
4 n RFKBES30VEC DIGITAL P.C.B. 1 2* RTL
4 n VEP79104F DIGITAL P.C.B. 1 3* RTL
6 VWJ1727 FFC 1
7 VWJ1728 FFC 1
8 VWJ1776 FFC 40P 1
9 REED0001 DRIVE POWER CABLE U 1
10 VKA0382 LEG CUSHION 2
11 RGR0356A-B1 REAR PANEL 1
1*
11 RGR0356A-A1 REAR PANEL 1
2*,3*
12 RMA1897 CENTER ANGLE 1
13 RMA1905 DVD ANGLE 1
14 RMC0632 EARTH SPRING (T) 1
15 RMC0637 EARTH SPRING (C) 1
16 RMC0622 EARTH SPRING (DI) 1
17 RMA1914 DIGITAL ANGLE 1
18 VMX3398 MECHA SPACER(F) 1
19 VMX3229 MECHA SPACER(R) 1
27 REPLACEMENT PARTS LIST
91
DMR-ES30VEG / DMR-ES30VEC / DMR-ES30VEB
