Panasonic DMR-ES30VEG

Ref.
No.
Part No. Part Name &
Decription
PCS Remarks
20 VMZ3452 BARRIER 1
21 VKC0412 MINI CLAMPER 1
22 VKC0554 P.C.B. SUPPORT
4(MECHA)
1
23 RMG0677-K DAMPER 4
24 RHD30111 SCREW 10
25 VHD0690-1 SCREW 8
26 VHD1452-2 SCREW(R4MECH L) 1
27 VHD1453-2 SCREW(R4MECH S) 3
28 RHD30115 SCREW DRIVE 3
29 VHD1092-1 SCREW(BT3+10) 1
30 VHD1662 SCREW(DAMPER) 4
31 XTV26+6FFJ SCREW 1
32 L6FAKCCE0004 FAN DVD-REC 1
33 n VEP04885C FRONT JACK P.C.B. 1 RTL
34 n VEP07A78C FL DRIVE P.C.B. 1 RTL
35 RHD26045 SCREW (PANEL) 8
36 RYP1278D-S1 FRONT PANEL 1 1*
36 RYP1278C-S1 FRONT PANEL 1 2*,3*
36-1 RKF0724-S DOOR 1
36-2 RGU2369-W POWER BUTTON 1
36-3 RGU2370-S EJECT BUTTON ES30V 1
36-4 RGU2372D-S PLAY BUTTON VHS 1
36-5 RGU2371-S OPEN BUTTON DVD 1
36-6 RGU2373D-S PLAY BUTTON DVD 1
36-7 RGL0673-W PANEL LIGHT 1
36-8 RXQ1300 DUB BUTTON UNIT 1
36-9 RKF0722A-S BLINDER PANEL 1
36-10 RKF0723-S1 TRAY DOOR 1
36-11 VMB2521 BLINDER SPRING (VHS) 1
36-12 VMB3410 BLINDER SPRING (DVD) 1
37 RHD30111 SCREW 1
38 VGM2077 TOP PANEL 1
39 RHD30113 SCREW TOP CASE SIDE 4
40 VHD0690-1 SCREW 3
41 RKA0178-X LEG 2
42 VKC0612 P.C.B. SPACER 1
43 VKC0295 MINI CARD SPACER 1
44 VKC0295 MINI CARD SPACER 1
45 VHD0690-1 SCREW (FAN) 2
46 XSN3+4FJK SCREW (TUNER) 1
47 K2KA29A00013 COAX CABLE 2
48 RHD30111 SCREW 1
27.3. PRINTED CIRCUIT BOARDS
INCLUDED IN MAIN P.C.B.
Ref. No. Part No. Part Name &
Description
PCS Remarks
TU7401 ENG37A08GF TUNER 1
1*
TU7402 ENG37A08GF TUNER 1
1*
TU7401 ENG37A07GF TUNER 1
2*
TU7402 ENG37A14GF TUNER 1
2*
TU7401 ENG37A17GF TUNER 1
3*
TU7402 ENG37A17GF TUNER 1
3*
DE7402 n VEP07A51A DECODER P.C.B. 1 1* RTL
DE7401 n VEP07A51B DECODER P.C.B. 1 1* RTL
DE7401 n VEP07A51F DECODER P.C.B. 1 2* RTL
DE7402 n VEP07A51F DECODER P.C.B. 1 2* RTL
DE7401 n VEP07A51E DECODER P.C.B. 1 3* RTL
DE7402 n VEP07A51E DECODER P.C.B. 1 3* RTL
27.4. PACKING & ACCESSORIES
PARTS
Ref.
No.
Part No. Part Name &
Description
PCS Remarks
A1 EUR7720KT0 REMOTE CONTROL 1 1*
A1 EUR7720KS0 REMOTE CONTROL 1 2*,3*
A2 UR77EC2003 BATTERY COVER 1
A3 RJA0043-1C POWERCORD 1
2*,3*
A3 RJA0044-3C POWER CORD 1
1*
A4 K1TWACC00001 RF CABLE 1
A5 K2KA6CA00001 AV CORD 1
A6 VPK2246 ACC.BOX 1
A7 RPFD0003 PAPER BAG 1 1*
A7 RPFD0001 PE-BAG 1 2*,3*
A8 RQTD0159-1B
ENGLISH-UK
O/I BOOK
(ES30V/EB)A5
1 1*
A8 RQTD0151-1D
GERMAN
O/I BOOK
(ES30V/EG)A5
1 2*,3*
A8 RQTD0152-1V
ITATALIAN
O/I BOOK
(ES30V/EG)A5
1 2*,3*
A8 RQTD0153-1H
DUTCH
O/I BOOK
(ES30V/EG)A5
1 2*,3*
A8 RQTD0155-1A
ENGLISH-CONT.
O/I BOOK
(ES30V/EG)A5
1 2*,3*
A8 RQTD0154-1C
FRECH
O/I BOOK
(ES30V/EG)A5
1 2*
A8 RQTD0156-1M
SPANISH
O/I BOOK
(ES30V/EG)A5
1 2*
A8 RQTD0157-1Z
SWEDISH
O/I BOOK
(ES30V/EG)A5
1 2*
A8 RQTD0158-1J
DANISH
O/I BOOK
(ES30V/EG)A5
1 2*
A8 RQCAD0020 QUICK START GUIDE 1 1*
PC1 RPG7555-1 PACKING CASE ES30VEB 1 1*
PC1 RPG7628-1 PACKING CASE ES30VEC 1 2*
PC1 RPG7554-1 PACKING CASE ES30VEG 1 3*
PC2 RPFD0004 MIRAMAT BAG 1
PC3 RPN1797A CUSHION(LEFT) 1
PC4 RPN1797B CUSHION(RIGHT) 1
27.5. ELECTRICAL PARTS
Ref. No. Part No. Part Name &
Description
PCS Remarks
C1101 ECQU2A683MLC X2 CAPACITOR 1
C1102 ECQU2A683MLC X2 CAPACITOR 1
C1103 EEUED2G680E CAPACITOR 1
C1104 F0C2G473A022 CAPACITOR 1
C1105 ECKN3A101KBP CERAMIC CAPACITOR 1
C1106 ECKN3A101KBP CERAMIC CAPACITOR 1
C1107 F1H1C474A095 CHIP CAPACITOR 1
C1108 F2A1V3300027 ALU ELEC CAPACITOR 1
C1109 F1H1H1020005 CHIP CAPACITOR 1
C1110 ECKWNA101MBV CERAMIC CAPACITOR 1
C1111 ECKWNA101MBV CERAMIC CAPACITOR 1
C1112 F1BAF471A013 CERAMIC CAPACITOR 1
C1201 EEUFM1E471B CAPACITOR 1
C1203 EEUFM1C152B CAPACITOR 1
C1204 EEUFM1C152B CAPACITOR 1
C1205 F1H1H104A220 CHIP CAPACITOR 1
C1206 F1H1H104A220 CHIP CAPACITOR 1
C1207 F1H1C104A042 CHIP CAPACITOR 1
C1208 ECJ1VC1H181J CHIP CAPACITOR 1
C1209 F2A1A681A540 ALU ELEC CAPACITOR 1
C1210 ECA1AHG102B ALU ELEC CAPACITOR 1
C1211 ECJ2FB1C334K CHIP CAPACITOR 1
C1212 F1H1C333A041 CHIP CAPACITOR 1
C1214 ECA1CHG471B ALU ELEC CAPACITOR 1
C1216 F1H1H104A220 CHIP CAPACITOR 1
C1217 EEUFM1C121B ALU ELEC CAPACITOR 1
C1218 F1H1H1030007 CHIP CAPACITOR 1
C1219 ECJ1VB1H331K CHIP CAPACITOR 1
C1220 F1H1C104A042 CHIP CAPACITOR 1
92
DMR-ES30VEG / DMR-ES30VEC / DMR-ES30VEB
