Ref. No. Part No. Part Name &

Description

PCS Remarks

C9707 F1H1H104A220 CHIP CAPACITOR 1

C9709 F1H1H100A735 CHIP CAPACITOR 1

C9710 F1H1H100A735 CHIP CAPACITOR 1

C9711 F1H1H100A735 CHIP CAPACITOR 1

C9712 F1H1H100A735 CHIP CAPACITOR 1

C9713 F1H1H104A748 CHIP CAPACITOR 1

C9714 F1H1H104A748 CHIP CAPACITOR 1

C9715 F1H1H1030007 CHIP CAPACITOR 1

C9716 F1H1H1030007 CHIP CAPACITOR 1

C9717 F1H1H1030007 CHIP CAPACITOR 1

C9718 F1H1H1030007 CHIP CAPACITOR 1

C9719 F1H1H1030007 CHIP CAPACITOR 1

C9720 F1H1H104A220 CHIP CAPACITOR 1

C9723 F1H1H104A220 CHIP CAPACITOR 1

C9724 F1H1H104A220 CHIP CAPACITOR 1

C9725 F1H1A1050029 CHIP CAPACITOR 1

C9726 F1H1H104A220 CHIP CAPACITOR 1

C9729 F1H1H100A735 CHIP CAPACITOR 1

C9730 F1H1H100A735 CHIP CAPACITOR 1

C9731 F1H1H100A735 CHIP CAPACITOR 1

C9732 F1H1H100A735 CHIP CAPACITOR 1

C9733 F1H1H1010005 CHIP CAPACITOR 1

C9735 F1H1H1030007 CHIP CAPACITOR 1

C9736 F1H1H1030007 CHIP CAPACITOR 1

C9737 F4D55473A013 ALU ELEC CAPACITOR 1

C9738 ECJ1VC1H180J CHIP CAPACITOR 1

C9739 ECJ1VC1H180J CHIP CAPACITOR 1

C9740 F1H1A1050029 CHIP CAPACITOR 1

C9741 F1H1H104A220 CHIP CAPACITOR 1

C9742 ECJ1VC1H180J CHIP CAPACITOR 1

C9745 ECJ1VC1H180J CHIP CAPACITOR 1

C9747 F1H1H104A220 CHIP CAPACITOR 1

C9748 F1H1H104A220 CHIP CAPACITOR 1

C9749 F1H1H104A220 CHIP CAPACITOR 1

C9750 F1H1H104A220 CHIP CAPACITOR 1

C9751 F1H1H4700004 CHIP CAPACITOR 1

C9752 F1H1H4700004 CHIP CAPACITOR 1

C9753 F1H1H4700004 CHIP CAPACITOR 1

C9754 F1H1H1030007 CHIP CAPACITOR 1

C9756 F1H1H1010005 CHIP CAPACITOR 1

C9757 ECJ1VB1A105K CHIP CAPACITOR 1

D1101 ERZVA5V471 SURGE ABSORBER 1

D1102 B0EALR000016 DIODE 1

D1103 B0EALR000016 DIODE 1

D1104 B0EALR000016 DIODE 1

D1105 B0EALR000016 DIODE 1

D1106 B0HADV000001 DIODE 1

D1107 MAZ42000MF DIODE 1

D1108 B0HAGM000008 DIODE 1

D1109 MAZ73000BF ZENER DIODE 1

D1201 B0JAMK000015 DIODE 1

D1202 B0JAMK000015 DIODE 1

D1203 B0JBSL000002 DIODE 1

D1204 B0JCPE000015 DIODE 1

D1205 B0JCPE000015 DIODE 1

D1501 B3EA00000072 DIODE 1

D2001 B0AACK000004 SWITCHING DIODE 1

D2002 B0AACK000004 SWITCHING DIODE 1

D2502 MAZ4160NMF DIODE 1

D3501 B0AACK000004 SWITCHING DIODE 1

D3901 B0AACK000004 SWITCHING DIODE 1

D4501 B0AACK000004 SWITCHING DIODE 1

D4502 MAZ4056NHF DIODE 1

D4901 MA2J11200L DIODE 1

D6306 MAZ4056NHF DIODE 1

D6401 B0AACK000004 SWITCHING DIODE 1

D6402 B0ACCK000005 DIODE 1

D7401 MAZ4300NMF DIODE 1

D7402 MAZ4300NMF DIODE 1

D7501 B3AAA0000752 DIODE 1

D7503 B3ACA0000273 DIODE 1

D7505 B3ADA0000173 DIODE 1

D7751 B0AACK000004 SWITCHING DIODE 1

Ref. No. Part No. Part Name &

Description

PCS Remarks

D7901 MAZ4220NMF DIODE 1

D7902 B0AAGM000007 DIODE 1

D7903 B0JAME000025 DIODE 1

D7904 MA2C18500E DIODE 1

D7905 MA2C18500E DIODE 1

D7906 MAZ4300NMF DIODE 1

D9101 B0JCPE000015 DIODE 1

D9102 B0JCPE000015 DIODE 1

D9104 MAZ40390HF DIODE 1

D9105 B0AACK000004 SWITCHING DIODE 1

D9106 B0AACK000004 SWITCHING DIODE 1

D9107 B0AACK000004 SWITCHING DIODE 1

DP7501 A2BB00000145 FL DISPLAY 1

F1101 K5D202BK0005 FUSE 1

FH1101 EYF52BCY FUSE HOLDER 1

FH1102 EYF52BCY FUSE HOLDER 1

IC1101 C0DACZZ00009 INTEGRATED CIRCUIT 1

IC1201 C0DBAKG00005 INTEGRATED CIRCUIT 1

IC1202 C0DAEMZ00001 VOLTAGE REGULATOR 1

IC1203 C0DAAJG00007 POWER SUPPLY IC 1

IC1511 B3NAA0000049 PHOTO COUPLER 1

IC1512 B3NAA0000049 PHOTO COUPLER 1

IC2501 C1AB00001767 MOTOR DRIVE IC 1

IC3001 C1AB00002080 INTEGRATED CIRCUIT 1

IC3002 C0CBCDD00007 POWER SUPPLY IC 1

IC3003 C1AB00001681 INTEGRATED CIRCUIT 1

IC3501 C1AB00001681 INTEGRATED CIRCUIT 1

IC3502 AN3293S-E2V INTEGRATED CIRCUIT 1

IC3901 C1AB00002100 INTEGRATED CIRCUIT 1

IC3902 C1AB00001681 INTEGRATED CIRCUIT 1

IC3903 C1AB00001682 INTEGRATED CIRCUIT 1

IC3904 C1AB00001682 INTEGRATED CIRCUIT 1

IC3906 C0CBCDD00006 INTEGRATED CIRCUIT 1

IC4501 AN3656NFBPBV INTEGRATED CIRCUIT 1

IC6001 C2CBJG000493 INTEGRATED CIRCUIT 1

IC6102 C1AB00001293 INTEGRATED CIRCUIT 1

IC6201 C0EBH0000172 INTEGRATED CIRCUIT 1

IC6302 C0CBCDC00020 POWER SUPPLY IC 1

IC7301 C1AB00002225 INTEGRATED CIRCUIT 1 1*,2*

IC7301 C0ZBZ0001081 INTEGRATED CIRCUIT 1 3*

IC7302 C0EAH0000051 RESET IC 1 1*,2*

IC7401 C0CBCDD00006 INTEGRATED CIRCUIT 1

IC7402 C0CBCDD00006 INTEGRATED CIRCUIT 1

IC7405 C0CBCDD00006 INTEGRATED CIRCUIT 1

IC7502 C0HBB0000048 INTEGRATED CIRCUIT 1

IC7801 PNA4618M13VT INTEGRATED CIRCUIT 1

IC9102 C0CBCDD00006 INTEGRATED CIRCUIT 1

IC9103 C0DBAKG00005 INTEGRATED CIRCUIT 1

IC9105 C0DAAJG00007 POWER SUPPLY IC 1

IC9106 C0DBEGD00002 POWER SUPPLY IC 1

IC9301 C0DBAHD00013 VOLTAGE REGULATOR 1

IC9302 C0ABBB000216 AMPLIFIERS 1

IC9303 C1AB00001486 INTEGRATED CIRCUIT 1

IC9304 C9ZB00000498 INTERGRATED CIRCUIT 1

IC9305 C0ABBB000119 INTEGRATED CIRCUIT 1

IC9701 C2CBKH000134 INTEGRATED CIRCUIT 1

IC9702 C0EBE0000194 VOLTAGE RESET IC 1

IC9703 C0EBH0000172 INTEGRATED CIRCUIT 1

IC9705 C3EBJC000055 INTEGRATED CIRCUIT 1

IC9706 C0EBE0000504 INTEGRATED CIRCUIT 1

IP1221 ERJ8GEY0R00V CHIP RESISTOR 1

IP4901 K5H5012A0010 FUSE 1

IP9101 K5H1022A0011 FUSE 1

IP9102 K5H5012A0010 FUSE 1

J1 VEE0U97 EARTH WIRE 1

JK3802 K1CB106A0012 CONNECTOR 1

JK3901 K1FB121B0018 CONNECTOR 1

JK3902 K1FB121B0018 CONNECTOR 1

JK4600 K2HA307A0009 CONNECTOR 1

JK4901 B3ZAZ0000017 OPTICAL LINK 1

JK9301 K1U412B00005 TERMINAL JACK 1

JK9302 K1CB306B0001 TERMINAL JACK 1

K3005 D0YBR0000002 CHIP RESISTOR 1

DMR-ES30VEG / DMR-ES30VEC / DMR-ES30VEB
