Panasonic DMR-EZ45VEB

Ref.
No.
Part No. Part Name &
Description
PCS Remarks
C9822 ECJ1VB1C105K CHIP CAPACITOR 1
C9823 ECJ1VB1C105K CHIP CAPACITOR 1
C9824 ECJ1VB1C105K CHIP CAPACITOR 1
C9825 ECJ1VB1C105K CHIP CAPACITOR 1
C9826 F1H1H1030006 CHIP CAPACITOR 1
C9827 ECJ1VB1C105K CHIP CAPACITOR 1
C9828 ECJ1VB1C105K CHIP CAPACITOR 1
C9829 ECJ1VB1C105K CHIP CAPACITOR 1
C9830 F1H1C104A042 CHIP CAPACITOR 1
C9831 ECJ1VB1C105K CHIP CAPACITOR 1
C9832 ECJ1VB1C105K CHIP CAPACITOR 1
C9833 ECJ1VB1C105K CHIP CAPACITOR 1
C9834 F1H1C104A042 CHIP CAPACITOR 1
C9835 ECJ1VB1C105K CHIP CAPACITOR 1
C9836 F1H1H1030006 CHIP CAPACITOR 1
C9839 ECJ1VC1H102J CHIP CAPACITOR 1
C9903 F2H1C100A013 CAPACITOR 1
C9904 F2H1H1R0A006 CAPACITOR 1
C9905 F2H1H1R0A006 CAPACITOR 1
C9906 F2H1C100A013 CAPACITOR 1
C9909 ECJ1VC1H070D CHIP CAPACITOR 1
C9910 ECJ1VC1H070D CHIP CAPACITOR 1
C9911 ECJ1VC1H070D CHIP CAPACITOR 1
C9912 ECJ1VC1H070D CHIP CAPACITOR 1
C9913 ECJ1VF1C105Z CHIP CAPACITOR 1
C9914 ECJ1VF1C105Z CHIP CAPACITOR 1
C9915 ECJ1VF1C105Z CHIP CAPACITOR 1
C9916 ECJ1VF1C105Z CHIP CAPACITOR 1
C9917 F1H1H1510001 CHIP CAPACITOR 1
C9918 F1H1H1510001 CHIP CAPACITOR 1
CN9001 K1KB11B00013 CONNECTOR 1
CN9003 K1KB12B00030 CONNECTOR 1
D1101 ERZVA5V471 SURGE ABSORBER 1
D1102 B0EALR000016 DIODE 1
D1103 B0EALR000016 DIODE 1
D1104 B0EALR000016 DIODE 1
D1105 B0EALR000016 DIODE 1
D1106 B0HADV000001 DIODE 1
D1107 MAZ42000MF DIODE 1
D1108 B0HAGM000008 DIODE 1
D1109 MAZ73000BF ZENER DIODE 1
D1203 B0JBSL000002 DIODE 1
D1204 B0JCPD000021 DIODE 1
D1205 B0JCPE000015 DIODE 1
D1208 B0JCPE000015 DIODE 1
D1501 B3EA00000072 DIODE 1
D1801 B0JCPE000015 DIODE 1
D2001 B0AACK000004 SWITCHING DIODE 1
D2002 B0AACK000004 SWITCHING DIODE 1
D2502 MAZ4160NMF DIODE 1
D3901 B0AACK000004 SWITCHING DIODE 1
D4501 B0AACK000004 SWITCHING DIODE 1
D4502 MAZ4056NHF DIODE 1
D4901 MA2J11200L DIODE 1
D56101 MA2J72800L DIODE 1
D6306 MAZ4056NHF DIODE 1
D6401 B0AACK000004 SWITCHING DIODE 1
D6402 B0ACCK000005 DIODE 1
D7301 MA2C165001VT DIODE 1
D7501 B3ABA0000595 LED 1
D7502 B3ACA0000273 DIODE 1
D7503 B3ADA0000173 DIODE 1
D7504 B3AAA0000752 DIODE 1
D7803 MA2C165001VT DIODE 1
D7805 MAZ40390HF DIODE 1
D7807 MAZ4300NMF DIODE 1
D7901 B0BA03600021 DIODE 1
D7903 B0AADM000003 DIODE 1
D7904 B0AADM000003 DIODE 1
D7905 B0JAMD000026 DIODE 1
D7906 MAZ4220NLF DIODE 1
D7907 MAZ4180NHF DIODE 1
D7908 MA2C165001VT DIODE 1
Ref.
No.
Part No. Part Name &
Description
PCS Remarks
D9104 MAZ40390HF DIODE 1
D9105 B0AACK000004 SWITCHING DIODE 1
D9106 B0JACE000001 DIODE 1
D9107 B0AACK000004 SWITCHING DIODE 1
D9201 B0CCAB000039 DIODE 1
D9702 MA2C72300F DIODE 1
DP7501 A2BD00000157 FL DISPLAY 1
F1101 K5D202BK0005 FUSE 250V / 2 AT 1
FH1101 EYF52BCY FUSE HOLDER 1
FH1102 EYF52BCY FUSE HOLDER 1
FL6101 F1H0J1050025 CERAMIC CAPACITOR 1
FL6102 F1H0J1050025 CERAMIC CAPACITOR 1
FL6103 F1H0J1050025 CERAMIC CAPACITOR 1
FL6104 F1H0J1050025 CERAMIC CAPACITOR 1
FL6105 F1H0J1050025 CERAMIC CAPACITOR 1
FL6106 F1H0J1050025 CERAMIC CAPACITOR 1
FL6110 F1H0J1050025 CERAMIC CAPACITOR 1
FP6101 K1MN40AA0082 CONNECTOR 1
IC1101 C0DACZZ00009 INTEGRATED CIRCUIT 1
IC1201 C0DBAKG00007 POWER SUPPLY IC 1
IC1202 C0DAEMZ00001 VOLTAGE REGULATOR 1
IC1203 C0DBAJG00011 POWER SUPPLY IC 1
IC1204 C0DBAJG00011 POWER SUPPLY IC 1
IC1501 B3NAA0000118 GAP SENSOR 1
IC1502 B3NAA0000118 GAP SENSOR 1
IC1801 C0DBAJG00011 POWER SUPPLY IC 1
IC2501 C1AB00001767 MOTOR DRIVE IC 1
IC3001 C1AB00002084 INTEGRATED CIRCUIT 1
IC3002 C0CBCDD00026 POWER SUPPLY IC 1
IC3901 C1AB00002379 INTEGRATED CIRCUIT 1
IC3905 C1AB00001340 INTEGRATED CIRCUIT 1
IC4501 AN3656NFBPBV INTEGRATED CIRCUIT 1
IC6001 C2CBHF000469 VHS MICON IC 1
IC6101 C0JBAZ002116 INTEGRATED CIRCUIT 1
IC6102 C0JBAZ002116 INTEGRATED CIRCUIT 1
IC6103 MN8647011 HDMI LSI IC 1
IC6104 C0CBCBD00048 POWER SUPPLY IC 1
IC6105 C0CBCDC00052 POWER SUPPLY IC 1
IC6107 C0JBAB000604 INTEGRATED CIRCUIT 1
IC6302 C0CBCDC00020 POWER SUPPLY IC 1
IC7301 C1AB00002225 INTEGRATED CIRCUIT 1
IC7401 C0CBCDD00025 POWER SUPPLY IC 1
IC7402 C0CBCDD00025 POWER SUPPLY IC 1
IC7403 C0CBCDD00025 POWER SUPPLY IC 1
IC7501 C0HBB0000044 DISPLAY DRIVER IC 1
IC7502 B3RAD0000073 IR RECEIVER 1
IC9001 C1AB00002208 INTEGRATED CIRCUIT 1
IC9102 C0CBCDD00025 POWER SUPPLY IC 1
IC9106 C0CBCBD00048 POWER SUPPLY IC 1
IC9201 C0JBAB000706 INTEGRATED CIRCUIT 1
IC9301 C3ABQG000083 SDRAM 1
IC9301 C0DBAHD00013 VOLTAGE REGULATOR 1
IC9302 C3FBMD000166 16 MBIT LOW VOLTAGE 1
IC9302 C0ABBB000216 AMPLIFIERS 1
IC9303 C0EBE0000504 INTEGRATED CIRCUIT 1
IC9305 C0ABBB000119 INTEGRATED CIRCUIT 1
IC9700 B3ZAZ0000017 OPTICAL LINK 1
IC9702 C0EBE0000194 VOLTAGE RESET IC 1
IC9703 C0EBJ0000336 RESET IC 1
IC9704 C2CBJG000733 MICON IC 1
IC9705 RFKFM6016K EEPROM IC 1 SPC
IC9706 C0EBE0000504 INTEGRATED CIRCUIT 1
IC9901 C0ABBB000216 AMPLIFIERS 1
IP1221 ERJ8GEY0R00V CHIP RESISTOR 1
IP1231 ERJ8GEY0R00V CHIP RESISTOR 1
IP1801 ERJ8GEY0R00V CHIP RESISTOR 1
IP4901 K5H5012A0010 FUSE 1
IP7901 D0YBR0000020 CHIP RESISTOR 1
IP9102 K5H5012A0010 FUSE 1
J1 VEE0U97 EARTH WIRE 1
JK3901 K1FB121B0018 CONNECTOR 1
JK3902 K1FB121B0018 CONNECTOR 1
JK4801 K2HA307A0009 CONNECTOR 1
100
DMR-EZ45VEB
