Panasonic DMR-EZ45VEB

Notes:
*Important safety notice:
Components identified by
mark have special
characteristics important for safety.
Furthermore, special parts which have purposes of fire-
retardant (resistors), high-quality sound (capacitors), low-
noise (resistors), etc. are used.
When replacing any of components, be sure to use only
manufactures specified parts shown in the parts list.
*Warning: This product uses a laser diode. Refer to caution
statements.
*Capacity values are in microfarads (µF) unless specified
otherwise, P=Pico-farads (pF), F=Farads (F).
*Resistance values are in ohms, unless specified otherwise,
1K=1,000 (OHM), 1M=1,000k (OHM).
*The marking (RTL) indicates the retention time is limited
for this item. After the discontinuation of this assembly in
production, it will no longer be available.
*All parts except parts mentioned [SPC] in the Remarks
column are supplied from PAVCG.
*Parts mentioned [SPC] are supplied from PAVC
17.1. CASING PARTS & PRINTED
CIRCUIT BOARDS
Ref.
No.
Part No. Part Name &
Description
PCS Remarks
1
&block
;
RFKNEZ45VEB RAM/DIGITAL PCB
MODULE
1 RTL
2
&block
;
REPD0026E MAIN PCB UNIT 1 RTL
3 RFKBD0033B DIGIT INTERF UNIT 1 RTL
4
&block
;
REPD0046B SD/DV PCB UNIT 1 RTL
6 VWJ1727-RW FFC 1
7 VWJ1728-RW FFC A/C HEAD 1
9 RKA0178-X LEG 2
10 VKA0382 LEG CUSHION 2
11 RGRD0009A-A1 REAR PANEL 1
12 RMQ1513 HEAT TRANSFER SHEET 1
13 RMC0672 PLATE SPRING 1
14 RMY0357 HEAT SINK 1
15 RMZD0003-2 DIGITAL PCB BARRIER 1
16 VKC0295 MINI CARD SPACER 2
18 RMX0354 MECHA SPACER (F) 1
19 RMX0355 MECHA SPACER (R) 1
20 VMZ3452 BARRIER 1
21 RMRD0003 CABLE CLAMPER 1
22 VKC0554 PCB SUPPORT 4(MECHA) 1
23 VKC0295 MINI CARD SPACER 1
24 RHD30111-3 SCREW 25
25 VHD0690-1 SCREW 15
26 VHD1770 SCREW 1
27 RHDC0023 SCREW 3
29 VHD1092-1 SCREW 1
31 XTV26+6FFJ SCREW 1
32 L6FAYYYE0001 FAN MOTOR 1
33
&block
;
REPD0035A FRONT JACK PCB 1 RTL
34
&block
;
REPD0036B FL DRIVE UNIT 1 RTL
35 RHD26045 SCREW (PANEL) 11
Ref.
No.
Part No. Part Name &
Description
PCS Remarks
36 RMCD0002 EARTH SPRING (FRONT) 1
37 RYP1336-S FRONT PANEL UNIT 1
37-1 RKF0757A-S BLINDER PANEL 1
37-2 RKF0758A-S1 TRAY DOOR 1
37-3 RKW0811A-Q FRONT WINDOW 1
37-4 RKW0810-Q FR WINDOW 1
37-5 RGU2475-S DUB BUTTON 1
38 RKMD0006-S TOP PANEL 1
39 RHD30113 SCREW TOP CASE SIDE 4
40 RMAD0006 DVD ANGLE (R) 1
41 RMAD0005 DVD ANGLE (F) 1
42 RMAD0009 DVD BRACKET 1
43 VHD1092-1 SCREW 1
44 RMC0632 EARTH SPRING (T) 1
46 XSN3+4FJK SCREW (TUNER) 2
47 REZD0023-1 SD/DV-DIGITAL FFC 1
48 RMCD0001 EARTH SPRING (ANGLE) 1
49 DV-IN UNIT RYQD0001 1
50
&block
;
REPD0031E BACKEND PCB UNIT 1 RTL
51
&block
;
VEP73137AB HDMI PCB UNIT 1 RTL
51-1 REED0002 FFC HDMI CABLE UNIT 1
17.2. VHS MECHANISM PARTS
Ref.
No.
Part No. Part Name &
Description
PCS Remarks
101 VEG1699KIT RDD CYLINDER 1
101-1 VMD5464 FPC HOLDER 1
102 VEM0800T CAPSTAN MOTOR 1
103 L1AZ00000004 FE HEAD 1
104 VDB1431 TENSION ARM BOSH 1
105 VDG1686 INTERMEDIATE GEAR 1
106 VDG1685 MAIN CAM GEAR 1
107 VDG1512-1 IDLER GEAR 2
108 VDG1514-3 CHANGE GEAR 1
109 VDR0372A REEL TABLE 2
110 VDV0391-2 CAPSTAN BELT 1
111 VEM0797 LOADING MOTOR 1
111-1 VDG1637 WORM GEAR 1
111-2 VMD4987 WORM BEARING 1
112 VMB3550A CHANGING GEAR SPRING 1
114 VMD5466 OPENER PIECE 1
115 VMD4253-1 LED PRISM 1
116 VML3934 MAIN LEVER 1
117 VML3933 PINCH CHARGE ARM 1
118 VML3632 IDLER ARM 1
119 VMX3092 P4 CAP 1
120 VXA7105-3 S SHAFT HOLDER 1
121 VXA7106-3 T SHAFT HOLDER 1
122 L1AE00000044 AC HEAD 1
122-1 VHD1066-2 SCREW 2
122-2 VHD1185 SCREW 1
124 VXL3107 S LOADING ARM 1
125 VXL3108 T LOADING ARM 1
126 VXL3109-7 PINCH ARM UNIT 1
127 VXL3110 P5 ARM 1
128 VXL3111-1 TENSION ARM 1
129 VXL3252 S BRAKE ARM 1
130 VXL3343 T BRAKE ARM 1
130-1 VMB3548-2A T BRAKE SPRING 1
131 VXL3124-2 CHANGING LEVER UNIT 1
132 VXP2133-2 CENTER CLUTH UNIT 1
133 VXP2168 TORQUE CLUTCH 1
134 VMA0L25 TOP PLATE 1
135 VMD5468 SIDE PLATE(L) 1
136 VMD5469 SIDE PLATE(R) 1
137 VXA8265 CASSETTE HOLDER UNIT 1
17 REPLACEMENT PARTS LIST
95
DMR-EZ45VEB
