Panasonic DMR-EZ45VEB

Ref.
No.
Part No. Part Name &
Description
PCS Remarks
138 VXL3160 MAIN SHAFT 1
139 VXA8323 SECTOR GEAR 1
141 VML3706-3 OPENER LEVER 1
142 VHD1044-1 SCREW 1
143 XYN3+C4FJ SCREW 1
144 XTN26+7JFJ SCREW 3
145 XTV26+5FFJ SCREW 2
146 XTV26+8FFJ SCREW 2
148 VHD1117-1 SCREW 3
149 VMX2208 WASHER 1
150 VMX3114 WASHER 1
151 VMX2699 WASHER 1
152 VMX3196 WASHER 1
17.3. PACKING & ACCESSORIES
PARTS
Ref.
No.
Part No. Part Name &
Description
PCS Remarks
A1 EUR7659YN0 REMOTE CONTROL 1
A2 UR76EC5903 BATTERY COVER 1
A3 K2CT3CA00004 POWERCORD 1
A4 K1TWACA00001 RF CABLE 1
A5 K1TWACC00001 RF CABLE 2
A6 K2KA6BA00003 AV CORD 1
A7 RPQFD0007 ACCESSORY BOX 1
A8 RPFD0007 PE-BAG,24cmx37cmx40 1
A9 RPQD0003 PAD (C) 1
A10 RQTD0201-2B O/I BOOK ENG UK 1
A10 RQCAD0029 QUICK START GUIDE 1
A10 RQCAD0035 REFERENCE GUIDE 1
A10 RQCB1364 CCP CARD FOR UK 1
A10 RQCC2704 DVD-MEDIA LEAFLET 1
PC1 RPG7929 CARTON BOX 1
PC2 RPFD0006 MIRAMAT BAG 1
PC3 RPN1860A CUSHION(LEFT) 1
PC4 RPN1860B CUSHION(RIGHT) 1
17.4. ELECTRICAL PARTS
Ref.
No.
Part No. Part Name &
Description
PCS Remarks
C1101 ECQU2A683MLC X2 CAPACITOR 1
C1102 ECQU2A683MLC X2 CAPACITOR 1
C1103 EEUED2G680E CAPACITOR 1
C1104 F0C2G473A022 CAPACITOR 1
C1105 ECKN3A101KBP CERAMIC CAPACITOR 1
C1106 ECKN3A101KBP CERAMIC CAPACITOR 1
C1107 ECJ1VB1C474K CHIP CAPACITOR 1
C1108 F2A1V3300027 ALU ELEC CAPACITOR 1
C1109 F1H1H1020005 CHIP CAPACITOR 1
C1110 ECKWNA101MBV CERAMIC CAPACITOR 1
C1111 ECKWNA101MBV CERAMIC CAPACITOR 1
C1112 F1BAF471A013 CERAMIC CAPACITOR 1
C1113 F1BAF221A013 CERAMIC CAPACITOR 1
C1201 EEUFM1E471B CAPACITOR 1
C1202 F2A1C221A019 ALU ELEC CAPACITOR 1
C1203 EEUFM1C152B CAPACITOR 1
C1204 EEUFM1C152B CAPACITOR 1
C1205 F1H1H104A731 CHIP CAPACITOR 1
C1206 F1H1C104A042 CHIP CAPACITOR 1
C1207 F1H1A2240004 CHIP CAPACITOR 1
C1208 ECJ1VC1H181J CHIP CAPACITOR 1
C1209 F2A1A681A540 ALU ELEC CAPACITOR 1
C1210 ECA1CHG471B ALU ELEC CAPACITOR 1
C1211 F1H1H1030007 CHIP CAPACITOR 1
C1212 F1H1C333A041 CHIP CAPACITOR 1
C1214 ECA1CHG471B ALU ELEC CAPACITOR 1
C1216 F1H1H104A731 CHIP CAPACITOR 1
C1217 EEUFM1C121B ALU ELEC CAPACITOR 1
C1218 F1H1H1030007 CHIP CAPACITOR 1
C1219 ECJ1VB1H331K CHIP CAPACITOR 1
Ref.
No.
Part No. Part Name &
Description
PCS Remarks
C1220 F1H1C104A042 CHIP CAPACITOR 1
C1222 F1H1C224A074 CHIP CAPACITOR 1
C1223 F2A1A681A540 ALU ELEC CAPACITOR 1
C1225 F1H1H1020005 CHIP CAPACITOR 1
C1231 EEUFM1E221B ALU ELEC CAPACITOR 1
C1232 F1H1E104A030 CHIP CAPACITOR 1
C1233 ECJ1VC1H391J CHIP CAPACITOR 1
C1234 F1H1C104A042 CHIP CAPACITOR 1
C1235 F1H1H1020005 CHIP CAPACITOR 1
C1236 F2A0J681A550 ALU ELEC CAPACITOR 1
C1237 ECJ1VB1A105K CHIP CAPACITOR 1
C1801 EEUFM1E221B ALU ELEC CAPACITOR 1
C1802 F1H1E104A030 CHIP CAPACITOR 1
C1803 F1H1H1030007 CHIP CAPACITOR 1
C1804 ECJ1VC1H391J CHIP CAPACITOR 1
C1805 F1H1C104A042 CHIP CAPACITOR 1
C1806 F1H1H1020005 CHIP CAPACITOR 1
C1808 F2A0J681A550 ALU ELEC CAPACITOR 1
C1809 ECJ1VB1A105K CHIP CAPACITOR 1
C2001 F1H1H330A736 CHIP CAPACITOR 1
C2003 F1H1A1050029 CHIP CAPACITOR 1
C2051 ECEA0JKN220B ALU ELEC CAPACITOR 1
C2053 ECEA1CKA100B ALU ELEC CAPACITOR 1
C2054 ECJ1VB1H392K CHIP CAPACITOR 1
C2055 F1H1E104A030 CHIP CAPACITOR 1
C2099 ECJ1VC1H681J CHIP CAPACITOR 1
C2501 F1H1E104A030 CHIP CAPACITOR 1
C2502 ECEA0JKA221B ALU ELEC CAPACITOR 1
C2503 ECJ1VB1A105K CHIP CAPACITOR 1
C2504 F1H1E223A029 CHIP CAPACITOR 1
C2505 F1H1E223A029 CHIP CAPACITOR 1
C2506 F1H1A2240004 CHIP CAPACITOR 1
C2507 F1H1H1020005 CHIP CAPACITOR 1
C2508 F1H1H182A219 CHIP CAPACITOR 1
C2509 ECEA1CKA220B ALU ELEC CAPACITOR 1
C2510 F1H1C104A042 CHIP CAPACITOR 1
C2511 F1H1C104A042 CHIP CAPACITOR 1
C2512 F1H1C104A042 CHIP CAPACITOR 1
C2513 F1H1A1050029 CHIP CAPACITOR 1
C2514 ECJ1VB1A105K CHIP CAPACITOR 1
C2515 F1H1H1030007 CHIP CAPACITOR 1
C2518 F1H1H1030007 CHIP CAPACITOR 1
C2519 F1H1H1030007 CHIP CAPACITOR 1
C2551 F1H1C473A071 CHIP CAPACITOR 1
C2552 ECJ1VB1C683K CHIP CAPACITOR 1
C2561 ECJ1VB1C683K CHIP CAPACITOR 1
C2562 F1H1C473A071 CHIP CAPACITOR 1
C2571 ECA1EM331B ALU ELEC CAPACITOR 1
C3001 F1H1H1510001 CHIP CAPACITOR 1
C3003 ECJ1VB1A105K CHIP CAPACITOR 1
C3004 F1H1C104A042 CHIP CAPACITOR 1
C3005 F1H1H2700003 CHIP CAPACITOR 1
C3006 F1H1C104A042 CHIP CAPACITOR 1
C3007 ECJ1VB1A105K CHIP CAPACITOR 1
C3008 F1H1H1030006 CHIP CAPACITOR 1
C3009 ECEA1HKA4R7B ALU ELEC CAPACITOR 1
C3010 ECJ1VB1A105K CHIP CAPACITOR 1
C3011 ECJ1VB1A105K CHIP CAPACITOR 1
C3012 ECEA0JKA470B ALU ELEC CAPACITOR 1
C3013 F1H1H1030007 CHIP CAPACITOR 1
C3015 F1H1C104A042 CHIP CAPACITOR 1
C3016 F1H1H4700004 CHIP CAPACITOR 1
C3017 ECJ1VB1A105K CHIP CAPACITOR 1
C3019 ECEA1CKA100B ALU ELEC CAPACITOR 1
C3020 ECJ1VC1H331J CHIP CAPACITOR 1
C3021 F1H1H1030007 CHIP CAPACITOR 1
C3023 ECEA1HKA3R3B ALU ELEC CAPACITOR 1
C3024 F1H1H1030006 CHIP CAPACITOR 1
C3026 ECJ1VB1A105K CHIP CAPACITOR 1
C3028 F1H1C104A042 CHIP CAPACITOR 1
C3029 F1H1C104A042 CHIP CAPACITOR 1
C3030 F1H1C104A042 CHIP CAPACITOR 1
C3033 F1H1C104A042 CHIP CAPACITOR 1
