General SpecificationsFP2 Multi-wire Link Unit
1-15
1.3 Restrictions When Combinations Are Used
1.3.3 Restrictions on the Number of Units that can be Installed
MEWNET mode Number of units installed
W mode
Up to three units can be installed for one CPU.
(If the Multi-wire link unit is one that can be used with PC link
communication, up to two of the three units can be installed.)
W2 mode
Up to three units can be installed for one CPU.
(If the Multi-wire link unit is one that can be used with PC link
communication, up to two of the three units can be installed.)
F mode
Up to four units can be installed for one CPU.
.
Notes
D
Of the intelligent units scheduled for future marketing, there
may be restrictions on the number of units that can be
installed if the unit is equipped with link functions.
D
The various MEWNET modes may be used in combination
within the individual ranges of restrictions that apply. For
instance, three W mode units may be used in combination with
three W2 mode units and four F mode units, for a maximum
number of ten multi-wire link units.
