Before You Start
FP2 Multi-wire Link Unit
iv
Before You Start
CPU Versions Supported
This unit supports CPU Ver. 1.05 and subsequent versions. Confirm the version on the
side panel seal on the CPU, or on the [STATUS DISPLAY] in the [MONITOR] menu of
the NPST-GR.
Selecting Cables
Cables which can be used with this unit vary depending on the mode being used. For
information on cable connections, refer to section 3.1.
Mode Cables used
MEWNET-W
MEWNET-W2
Twisted pair cable
MEWNET-F
Twisted pair cable, VCTF cable
About Selecting MEWNET-W2
In order to use the FP2 Multi-wire link unit in MEWNET-2 mode, the user must write
a program on a level of about 300 steps. Proceed only after carefully going over the
specifications.
Please inquire about more detailed materials regarding MEWNET-W2.
