Communication Parameters Settings
The example of communication settings of GT and PLC is shown below.
Setting Values for GT (Set in the configuration setting of GTWIN.)
Item
Setting
Baud Rate
9600/19200/38400/57600/115200 bps
Data Bits
8
Stop Bits
1
Parity
Even
KV-N10L Setting (port 1)
Item
Setting
Operation
KV mode(high link)
Baud rate
9600/19200/38400/57600/115200 bps
RS/CS flow control
Not used
Note:
-Use the port 1.
-Use a unit editor supplied with the KV BUILDER for the settings of the KV-N10L.
