Panasonic GT02

1-22
1.6 MELSEC-Q (CPU) Series
PLC model selection
Select "MELSEC-Q (CPU) series".
Usable devices
Bit/Word Device No. Memo
Bit
Device
Input Relay
X000000-X001FFF
Output Relay
Y000000-Y001FFF
Internal Relay
M000000-M032767
Latch relay
L000000-L032767
Annunciator
F000000-F032767
Edge relay
V000000-V032767
Link Relay
B000000-B007FFF
Special relay
SM000000-SM002047
Link special relay
SB000000-SB0007FF
Step relay
S000000-S008191
Timer(contact)
TS000000-TS023087
Timer(coil)
TC000000-TC023087
Retentive timer(contact)
SS000000-SS023087
Retentive timer(coil)
SC000000-SC023087
Counter(contact)
CS000000-CS023087
Counter(coil)
CC000000-CC023087
Word
Device
Input Relay
X000000-X001FF0
Specify address expression every 0
Output Relay
Y000000-Y001FF0
Specify address expression every 0
Internal Relay
M000000
-M032752
Specify address expression every 16
multiples
Latch relay
L000000-L032752
Annunciator
F000000-F032752
Edge relay
V000000-V032752
Link Relay
B000000-B007FF0
Specify address expression every 0
Special relay
SM000000-SM002032
Link special relay
SB000000-SB0007F0
Step relay
S000000-S008176
Timer(current)
TN000000-TN023087
Retentive timer(Current value)
SN000000-SN023087
Counter(current)
CN000000-CN023087
Data Register
D000000-D025983
Link Register
W000000-W00657F
Link special register
SW000000-SW0007FF
File Register(for block
number)
R000000
-R032767
File register(for sequential
number)
ZR000000
-ZR1042431
Special register
SD000000-SD002047
