Panasonic GT02

2-14
2.2 Omron SYSMAC-CS/CJ Series
PLC model selection
Select "Omron SYSMAC-CS/CJ series".
Usable devices vary according to the version of GTWIN.
There is a restriction on the version of GT firmware if the GTWIN is Ver2.96 or later.
GT Series
GTWIN Version
GT Version
GT01
Ver.2.96 or later
Ver.1.343 or later
GT05
Ver.1.00 or later
GT11
Ver.1.241 or later
GT21
Ver.1.141 or later
GT32
Ver.1.03 or later
GT02
Ver.2.A0 or later
Ver.1.00 or later
GT12
Ver.2.97 or later
Ver.1.00 or later
GT02L
Ver.2.B0 or later
Ver.1.00 or later
GT32-E
Ver.2.C0 or later
Ver.1.00 or later
GT03-E
Ver.2.D0 or later
Ver.1.00 or later
Usable devices(When the version of GTWIN is Ver.2.96 or later)
Bit/Word Device
No.
Memo
Bit Device
I/O Relay
Internal Hold Relay
Special Auxiliary Relay
Analog setting value storage area
0000.00~9999.15
*1
Data link Relay
L 0000.00~L 9999.15
*1
Auxiliary Memory Relay
A 0000.00~A 9999.15
*1
Hold Relay
H0000.00~H 9999.15
*1
Timer(contact)
T 0000~T 4095
*1
Counter(contact)
C 0000~C 4095
*1
Data memory
D 00000.00~D 32767.15
*1
Internal auxiliary relay
W 0000.00~W 9999.15
*1
Extended data memory (Current bank)
EW 00000.00~EW 32767.15
*1
Extended data memory (Bank designation)
E 0-00000.00~E 18-32767.15
*2
Task flag
TK 00~TK 31
*1
Word Device
I/O Relay
Internal Hold Relay
Special Auxiliary Relay
Analog setting value storage area
0000~9999
Data link Relay
L 0000~L 9999
Auxiliary Memory Relay
A 0000~A 9999
Hold Relay
H 0000~H 9999
Timer(current)
T 0000~T 4095
Counter(current)
C 0000~C 4095
Data Memory
D 00000~D 32767
Internal auxiliary relay
W 0000~W 9999
Extended data memory (Current bank)
EM 00000~EM 32767
Extended data memory (Bank designation)
E 0-00000~E 18-32767
*3
Double Word
Device
Index register
IR 00~IR 15
