Panasonic GT02

1-2
1.1 MELSEC-FX1S/ FX1N/ FX1NC Series
PLC model selection
Select “Mitsubishi MELSEC-FX Series".
Usable devices
Bit/Word Device
No.
Memo
Bit
Device
Input Relay
X0000-X0337
Output Relay
Y0000-Y0337
Internal Relay
M0000-M1535
State
S0000-S0999
Timer(contact)
TS0000-TS0255
Counter(contact)
CS0000-CS0255
Word
Device
Input Relay
X0000-X0320
Specify address expression every 20
Output Relay
Y0000-Y0320
Specify address expression every 20
Internal Relay
M0000-M1520
Specify address expression every 16 multiples
State
S0000-S0976
Specify address expression every 16 multiples
Timer(current)
TN0000-TN0255
16 Bits Counter(current)
CN0000-CN0199
32 Bits Counter(current)
CN0200-CN0255
Data Register
D0000-D0999
Note1) The addresses you can use may differ depending on the model. For details, please see the
manual for the PLC you are using.
Note2) If using an input relay, output relay and auxiliary relay in word units, please set the address in 16
point increments from 000. (X000, X020, X040 …, M000, M016, M032).
Communication Parameters Settings
The example of communication settings of GT and PLC is shown below.
Setting Values for GT (Set in the configuration setting of GTWIN.)
Item
Setting
Baud Rate
9600bps
Data Length
7
Stop Bits
1
Parity
Even
Setting the communication conditions for the PLC
“0” should be stored in D8120. (“0” is the default value, so this setting should not need to be entered by
the user.)
