2.1 Omron SYSMAC-C Series (C/α/CV/CP1)
PLC model selection
Select "Omron SYSMAC-C series."
Usable devices
Bit/Word Device
No.
Bit Device
I/O Relay
Internal Hold Relay
Special Auxiliary Relay
000000
-614315
Data link Relay
LR00000-LR19915
Auxiliary Memory Relay
AR00000-AR95915
Hold Relay
HR00000-HR51115
Timer(contact)
TIM0000-TIM4095
Counter(contact)
CNT0000-CNT4095
Word Device
I/O Relay
Internal Hold Relay
Special Auxiliary Relay
0000
-6143
Data link Relay
LR000-LR199
Auxiliary Memory Relay
AR000-AR959
Hold Relay
HR000-HR511
Timer(current)
TIM0000-TIM4095
Counter(current)
CNT0000-CNT4095
Data Memory
DM0000-DM9999
*For details, please consult the manual for the PLC you will use.
Note:
- The maximum value that can be set with the GT is described.
- The range of usable addresses differs depending on the model. For details, please consult the manual
for the PLC you will use.
- It is used with CS1 or CJ1, but the timer (TIM) and counter (CNT) cannot be used.
Set the PLC model to "Omron SYSMAC-CS/SJ Series" for using it.
