1.2.2 Using an Adapter
CPU
Adapter
Wiring diagram
GT Series
FX2N
FX2NC
FX2N
-232-BD
GT series
RS232C
24 V DC
typ
e*1 *2
FX3U
FX3UC
FX3UC
-232-BD
FX3U
-232-ADP
FX3G
FX3G
-232-BD
GT707
*1: Although nos.6 and 7 of the models except GT01 are RS/CS, they can be used in the above
connection.
*2: This is for RS232C type of GT01/GT02/GT02L/GT03-E/GT05/GT11/GT12/GT21/GT32/
GT32-E/GT703/GT704.
