3.1 PROVISOR TCmini Series
PLC model selection
Select “TOSHIBA MACHINE PROVISOR Tcmini Series”.
Usable devices
Bit/Word Device
No.
Bit Device
Input
X0000-X0F7F
Output
Y0000-Y0F7F
Internal Relay
R0000-R077F
Timer Relay
T0000-T077F
Counter Relay
C0000-C077F
Latch Relay
L0000-L007F
Edge Relay
E0000-E077F
Special Auxiliary Relay
A0000-A016F
Word Device
Input
X0000W-X00F7W
Output
Y0000W-Y00F7W
Internal Relay
R0000W-R0077W
Timer Relay
T0000W-T0077W
Counter Relay
C0000W-C0077W
Latch Relay
L0000W-L0007W
Edge Relay
E0000W-E0077W
Special Auxiliary Relay
A0000W-A0016W
Data Register
D0000-D0F7F
Timer Counter (current)
P0000-P077F
Timer Counter (set value)
V0000-V077F
The following list illustrates each expression of PLC device in GTWIN.
When you enter a value of devices, follow below expression.
Expression in PLC
Expression in GTWIN
Bit Device
R120
R120
Word Device
R12W/X12W/Y12W
RW12/XW12/YW12
