Panasonic GT02

2-18
2.2.1 SYSMAC CS1 series (1:1) (RS232C)
CPU
Link I/F
Wiring diagram
GT series
CS1H
-CPU67
CS1H
-CPU66
CS1H
-CPU65
CS1H
-CPU64
CS1H
-CPU63
CS1G
-CPU45
CS1G
-CPU44
CS1G
-CPU43
CS1G
-CPU42
RS232C port on
CPU unit
GT series
RS232C
type*
2 *3
CS1W-SCU21-V1
CS1W-SCB21-V1
CS1W
-SCB41-V1
GT707
*1: A connection cable for peripherals is required for the connection to the peripheral port.
*2: Although nos.6 and 7 of the models except GT01 are RS/CS, they can be used in the above
connection.
*3: This is for RS232C type of GT01/GT02/GT02L/GT03-E/GT05/GT11/GT12/GT21/GT32/
GT32-E/GT703/GT704.
