Printing
Adjusting the imprinter printing position
1. Move the carriage to the desired printing position, and align the indicator (A) with the " " mark (B) .
• The " " mark indicates the printing position. Printing is not available in any other position.
Printing Position
16.5 mm (0.6 in.)
30.8 mm (1.2 in.)
141 mm (5.6 in.)
121 mm (4.8 in.)
109.3 mm (4.3 in.)
97.5 mm (3.8 in.)
97.5 mm (3.8 in.)
83.5 mm (3.3 in.) 83.5 mm (3.3 in.)
66.8 mm (2.6 in.)
66.8 mm (2.6 in.)
56.5 mm (2.2 in.) 56.5 mm (2.2 in.)
45 mm (1.8 in.)
45 mm (1.8 in.)
30.8 mm (1.2 in.)
16.5 mm (0.6 in.)
Document size Document sizeCenter
Printing
Printing can be set from the ICP program and the TWAIN and ISIS drivers. For details, refer to the help for ICP
or PIE.
80 Operating Manual
