96
Others
VQT4M51 (ENG)
Interface
Digital “USB 2.0” (High Speed)
¢ Data from the PC can not be written to the camera using the
USB connection cable.
Analogue video/
audio
NTSC/PAL Composite (Switched by menu)
Audio line output (monaural)
Terminal
[REMOTE] φ 2.5 mm jack
[AV OUT/DIGITAL] Dedicated jack (8 pin)
[HDMI] MiniHDMI TypeC
[MIC] φ 3.5 mm jack
Headphone φ 3.5 mm jack
Flash synchro Available
Dimensions Approx. 132.9 mm (W)k93.4 mm (H)k82.0 mm (D)
[5.23q (W)k3.68q(H)k3.23q (D)]
(excluding the projecting parts)
Mass Approx. 550 g/1.21 lb
[with the card and battery]
Approx. 470 g/1.04 lb (camera body)
Approx. 855 g/1.88 lb
[with the Interchangeable lens (H-HS12035), card and battery]
Approx. 1010 g/2.23 lb
[with the Interchangeable lens (H-VS014140), card and battery]
Operating temperature 0 oC to 40 oC (32 oF to 104 oF)
Operating humidity 10%RH to 80%RH
Dust-proof and
splash-proof
Yes
