Panasonic Lumix DMC-LX1 User Manual

Preparation
13
VQT0S19
Charging the Battery with the Charger
When the camera is shipped, the battery is
not charged. Charge the battery before
use.
1 Attach the battery with attention
to the direction of the battery.
2 Connect the charger to the
electrical outlet.
• When the [CHARGE] indicator A lights
in green, charging starts.
• When the [CHARGE] indicator
A turns
off (in about 130 minutes), charging is
completed.
3 Detach the battery.
• After charging is completed, be sure to
disconnect the charger from the electrical
outlet.
• The battery becomes warm after use/
charge or during charge. The camera also
becomes warm during use. However, this
is not a malfunction with the camera.
• The battery will discharge if left for a long
time after charging. Recharge it.
• Use the dedicated charger and battery.
• Charge the battery with the charger
indoors.
• Do not disassemble or modify the
charger.
A

Panasonic Lumix DMC-LX1 Specifications

General

Megapixel	8.4 MP
Sensor type	CCD
Filter	Primary Color Filter
Digital zoom	22.5 x
Optical zoom	4 x
Focal length range	6.3 - 25.2 mm
Built-in flash	Yes
Dimensions (WxDxH)	105.7 x 25.6 x 55.8 mm
Camera shutter speed	60 - 1/2000 s
Focal length (35mm film equivalent)	28 - 112 mm
Internal memory	32 MB
Compatible memory cards	mmc, sd
Motion JPEG frame rate	30 fps
Maximum video resolution	848 x 480 pixels
Display diagonal	2.5 \
Display resolution (numeric)	207000 pixels
I/O ports	A/V Output (NTSC / PAL), USB.
Bundled software	LUMIX Simple Viewer, Photo Fun Studio, ArcSoft PhotoBase, ArcSoft PhotoImpression, ArcSoft Panorama Maker, USB Driver
Battery type	3.7 V, 1150 mAh
Product color	Black, Silver
Focus adjustment	Auto

Weight and Dimensions

Depth	25.6 mm
Width	105.7 mm
Height	55.8 mm
Weight	185 g
