Chapter 4 Settings — [NETWORK] menu
ENGLISH - 107
[NETWORK] menu
On the menu screen, select [NETWORK] from the main menu, and select an item from the sub-menu.
Refer to “Navigating through the menu” (
x
page 62) for the operation of the menu screen.
Note
f
The on-screen menu (menu screen) of the projector has not the network setting about the wireless LAN. When the wireless module (Model
No.: ET-WML100) of the optional accessories is inserted to the projector, please set the wireless LAN by accessing the projector via a
computer. For detailed, please refer to “Web control function” → “[Network cong] page” → “Wireless LAN” (
x
page 126).
[DIGITAL LINK MODE]
(Only for PT-EZ590, PT-EW650 and PT-EX620)
Switch the communication method of the <DIGITAL LINK/LAN> terminal of the projector.
1) Press as to select [DIGITAL LINK MODE].
2) Press qw to switch the item.
f
The items will switch each time you press the button.
[AUTO] Switches the communication method automatically to DIGITAL LINK, long reach or Ethernet.
[DIGITAL LINK] Fixes the communication method to DIGITAL LINK.
[LONG REACH] Fixes the communication method to long reach.
[ETHERNET] Fixes the communication method to Ethernet.
Possible communication modes
l
: Communication possible
―: Communication not possible
Setting
Communication possible
Image transmission
(100 m (328'1"))
Image transmission
(150 m (492'2"))
Ethernet RS-232C
[AUTO]
For DIGITAL LINK
l
―
l l
For long reach ―
l l l
For Ethernet ― ―
l
―
[DIGITAL LINK]
l
―
l l
[LONG REACH] ―
l l l
[ETHERNET] ― ―
l
―
Note
f
The maximum transmission distance when connected with the long-reach communication method is 150 m (492'2"). However, the signal
that the projector can receive is only up to 1080/60p (1 920 x 1 080 dots, dot clock frequency: 148.5 MHz).
f
When the communication method of the twist-pair-cable transmitter is set to long reach, it will connect with long-reach communication
method when [DIGITAL LINK MODE] is set to [AUTO]. To connect with the optional DIGITAL LINK Switcher (Model No.: ET-YFB200G) with
the long-reach communication method, set [DIGITAL LINK MODE] to [LONG REACH].
f
It will not connect correctly if the twist-pair-cable transmitter is not supporting the long-reach communication method even if [DIGITAL LINK
MODE] is set to [LONG REACH].
[DIGITAL LINK STATUS]
(Only for PT-EZ590, PT-EW650 and PT-EX620)
Display DIGITAL LINK connection environment.
1) Press as to select [DIGITAL LINK STATUS].
2) Press the <ENTER> button.
f
The [DIGITAL LINK STATUS] screen is displayed.
[LINK STATUS] Either [NO LINK], [DIGITAL LINK], [LONG REACH] or [ETHERNET] is displayed.
[HDCP STATUS] Either [NO SIGNAL], [OFF], or [ON] is displayed.
