Panasonic PT-EZ590

Chapter 4 Settings — [POSITION] menu
ENGLISH - 71
[POSITION] menu
On the menu screen, select [POSITION] from the main menu, and select an item from the sub-menu.
Refer to “Navigating through the menu” (
x
page 62) for the operation of the menu screen.
[REALTIME KEYSTONE]
The projector can correct the distortion of the projected image automatically when the projector is installed tilted.
1) Press as to select [REALTIME KEYSTONE].
2) Press qw or the <ENTER> button.
f
The [REALTIME KEYSTONE] individual adjustment screen is displayed.
3) Press qw to switch the item.
f
The items will switch each time you press the button.
[OFF] Does not execute the realtime keystone function automatically.
[ON] Executes the realtime keystone function automatically.
Note
f
Sometimes the realtime keystone function may not correct the image properly, the operation of the [SCREEN ADJUSTMENT] is required.
f
The [REALTIME KEYSTONE] function cannot work when the [FRONT/CEILING] or the [REAR/CEILING] feature is selected in [PROJECTION
METHOD] in the [PROJECTOR SETUP] menu.
[SCREEN ADJUSTMENT]
(For PT-EZ590)
You can correct the distortion of the projected image that occurs when the projector is installed tilted or when the
screen is tilted or curved.
1) Press as to select [SCREEN ADJUSTMENT].
2) Press the <ENTER> button.
f
The [SCREEN ADJUSTMENT] screen is displayed.
3) Press as to select one item to adjust.
[KEYSTONE] Adjusts when the trapezoid of the projected image is distorted.
[CORNER CORRECTION] Adjusts when the four corners of the projected image are distorted.
[CURVED CORRECTION] Adjusts when the linearity is not uniform or the projected image is curved distortion.
Setting [KEYSTONE]
1) Press as to select [SCREEN ADJUSTMENT].
2) Press the <ENTER> button.
f
The [SCREEN ADJUSTMENT] screen is displayed.
3) Press as to select [KEYSTONE].
4) Press the <ENTER> button.
f
The [KEYSTONE] individual adjustment screen is displayed.
5) Press as to select one item to adjust.
[LENS THROW RATIO] Set the throw ratio for the lens used.
[KEYSTONE] Adjusts when the trapezoid of the projected image is distorted.
[BALANCE] Adjusts according to the lens shift range in the horizontal or vertical direction.
