Panasonic PT-EZ590

Chapter 7 Appendix — Specications
160 - ENGLISH
r Terminal
<RGB 1 IN> terminal
1 set, (BNC x 5 (RGB/YP
B
P
R
/YC
B
C
R
x 1))
RGB signal 0.7 V [p-p] 75 Ω (SYNC ON GREEN: 1.0 V [p-p] 75 Ω)
SYNC/HD
TTL high impedance, automatic positive/negative
polarity compatible
VD
TTL high impedance, automatic positive/negative
polarity compatible
YP
B
P
R
signal Y: 1.0 V [p-p] including synchronization signal, P
B
P
R
: 0.7 V [p-p] 75 Ω
Y/C signal Y: 1.0 V [p-p], C: 0.286 V [p-p] 75 Ω
<RGB 2 IN> terminal
1 set high-density D-Sub 15 p (female)
RGB signal 0.7 V [p-p] 75 Ω (SYNC ON GREEN: 1.0 V [p-p] 75 Ω)
SYNC/HD
TTL high impedance, automatic positive/negative
polarity compatible
VD
TTL high impedance, automatic positive/negative
polarity compatible
(The SYNC/HD and VD terminals do not support 3 value SYNC.)
YP
B
P
R
signal Y: 1.0 V [p-p] including synchronization signal, P
B
P
R
: 0.7 V [p-p] 75 Ω
<MONITOR OUT> terminal
1 set, high-density D-Sub 15 p (female)
RGB signal 0.7 V [p-p] 75 Ω (SYNC ON GREEN: 1.0 V [p-p] 75 Ω)
SYNC/HD TTL high impedance, positive/negative polarity
VD TTL high impedance, positive/negative polarity
YP
B
P
R
signal Y: 1.0 V [p-p] including synchronization signal, P
B
P
R
: 0.7 V [p-p] 75 Ω
<VIDEO IN> terminal 1 set, pin jack 1.0 V [p-p] 75 Ω
<HDMI 1 IN>/<HDMI 2 IN>
terminal
2 sets, HDMI 19 pin, HDCP compatible, Deep Color compatible
Audio signal Linear PCM (Sampling frequency: 48 kHz/44.1 kHz/32 kHz)
<AUDIO IN 1>/<AUDIO IN 2>
terminal
2 sets, M3 stereo mini jack 0.5 V [rms], input impedance 22 kΩ or more
<AUDIO IN 3> terminal 1 set, pin jack x 2 (L-R) 0.5 V [rms], input impedance 22 kΩ or more
<VARIABLE AUDIO OUT>
terminal
1 set, M3 stereo mini jack (monitor output, stereo compatible)
0 V [rms] to 2.0 V [rms] (variable), output impedance 2.2 kΩ or less
<SERIAL IN> terminal 1 set, D-Sub 9 p, RS-232C compliant, for computer control
<REMOTE 1 IN> terminal 1 set, D-Sub 9 p, for external control
<REMOTE 2 IN> terminal 1 set, M3 stereo mini jack, for remote control (wired)
<DIGITAL LINK/LAN> terminal
*1
1 set, RJ-45, for network, DIGITAL LINK connection, PJLink compatible, 100Base-TX
<LAN> terminal
1 set, RJ-45, for network connection, PJLink compatible, 10Base-T/100Base-TX
<WIRELESS> terminal
USB connector (type A) x 1, for the Wireless module (Model No.: ET-WML100) only
<DC OUT> terminal
USB connector (type A) x 1, for power supply only (DC 5 V, maximum 900 mA)
*1 Only for PT-EZ590, PT-EW650 and PT-EX620
r Applicable scanning frequency
Refer to “List of compatible signals” (
x
page 156) for the types of video signals that can be used with the
projector.
For video signal Horizontal : 15.73 kHz Vertical : 59.94 Hz, Horizontal : 15.63 kHz Vertical : 50 Hz
For Y/C signal Horizontal : 15.73 kHz Vertical : 59.94 Hz, Horizontal : 15.63 kHz Vertical : 50 Hz
For RGB signal
f
Displayable resolution: 640 x 400 to 1 920 x 1 200
f
Dot clock frequency: 162 MHz or less
For YC
B
C
R
/YP
B
P
R
signal
f
Displayable resolution: 480i/576i to 1 920 x 1 080
f
Dot clock frequency: 148.5 MHz or less
f
The SYNC/HD and VD terminals do not support 3 value SYNC.
For HDMI signal
f
Displayable resolution for movie-based signals: 480i/576i
*1
to 1 920 x 1 080
Displayable resolution for still image signals: 640 x 400 to 1 920 x 1 200 (non-interlaced)
f
Dot clock frequency: 25 MHz - 162 MHz
*1 Pixel-Repetition signal (dot clock frequency 27.0 MHz) only
Note
f
DIGITAL LINK input compatible signal is the same as HDMI input compatible signal.
(Only for PT-EZ590, PT-EW650 and PT-EX620)
