Chapter 4 Settings — [TEST PATTERN] menu
98 - ENGLISH
[TEST PATTERN] menu
On the menu screen, select [TEST PATTERN] from the main menu.
Refer to “Navigating through the menu” (x page 55) for the operation of the menu screen.
f Press qw to switch.
[TEST PATTERN]
Display the test pattern built-in to the projector.
Settings of position, size, and other factors will not be reected in test patterns. Make sure to display the input signal before performing various
adjustments.
1) Press qw to switch the [TEST PATTERN] item.
f The items will switch each time you press the button.
Menu screen + Color bar
(vertical)
Displays test patterns with the menu screen. Select a test pattern so that it is easy to make various
adjustments.
Menu screen + Color bar
(horizontal)
Menu screen + 16 gradations
(vertical 1)
Menu screen + 16 gradations
(vertical 2)
Menu screen + 16 gradations
(horizontal 1)
Menu screen + 16 gradations
(horizontal 2)
Menu screen + Cross hatch
Menu screen + Aspect frame
Menu screen + All white
Menu screen + All black
Menu screen + Entry screen
Displays the menu screen and input signal.
Built-in test patterns are not displayed.
Note
f Press the <ON SCREEN> button on the remote control while the test pattern is displayed to hide the menu screen.
To Next Page
