Panasonic PT-RZ575

Chapter 7 Appendix — Specications
ENGLISH - 179
r Connecting terminal
<COMPUTER 1 IN> terminal
1 set, high-density D-Sub 15 p (female)
RGB signal 0.7 V [p-p] 75 Ω (SYNC ON GREEN: 1.0 V [p-p] 75 Ω)
SYNC/HD TTL high impedance, automatic positive/negative
polarity compatible
VD TTL high impedance, automatic positive/negative
polarity compatible
YP
B
P
R
signal Y: 1.0 V [p-p] including synchronization signal, P
B
P
R
: 0.7 V [p-p] 75 Ω
Y/C signal Y: 1.0 V [p-p], C: 0.286 V [p-p] 75 Ω
<COMPUTER 2 IN/1 OUT>
terminal
1 set, high-density D-Sub 15 p (female)
RGB signal 0.7 V [p-p] 75 Ω (SYNC ON GREEN: 1.0 V [p-p] 75 Ω)
SYNC/HD TTL high impedance, automatic positive/negative
polarity compatible
VD TTL high impedance, automatic positive/negative
polarity compatible
YP
B
P
R
signal Y: 1.0 V [p-p] including synchronization signal, P
B
P
R
: 0.7 V [p-p] 75 Ω
<DVI-D IN> terminal 1 set, DVI-D 24 p, single link, DVI 1.0 compliant, HDCP compatible
<HDMI 1 IN> terminal
<HDMI 2 IN> terminal
Total 2 sets, HDMI 19 p, HDCP compatible, Deep Color compatible
Audio signal Linear PCM (sampling frequency: 48 kHz/44.1 kHz/32 kHz)
<VIDEO IN> terminal 1 set, pin jack, 1.0 V [p-p] 75 Ω
<AUDIO IN 1> terminal 1 set, pin jack x 2 (L-R), 0.5 V [rms], input impedance 22 kΩ or more
<AUDIO IN 2> terminal
<AUDIO IN 3> terminal
Total 2 sets, M3 stereo mini jack, 0.5 V [rms], input impedance 22 kΩ or more
<VARIABLE AUDIO OUT>
terminal
1 set, M3 stereo mini jack (monitor output, stereo compatible), 0 V [rms] to 1.80 V [rms] (variable), output
impedance 2.2 kΩ or less
<SERIAL IN> terminal D-Sub 9 p, 1 set, RS-232C compliant, for computer control
<DIGITAL LINK/LAN> terminal
1 set, RJ-45, for network and DIGITAL LINK connections (HDBaseT
TM
compliant), PJLink compatible,
100Base-TX, Art-Net compatible, HDCP compatible, Deep Color compatible
<LAN> terminal 1 set, RJ-45, for network connection, PJLink compatible, 10Base-T/100Base-TX, Art-Net compatible
<DC OUT> terminal USB connector (type A) x 1, for power supply only (DC 5 V, maximum 900 mA)
