Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 107
[LIGHT OUTPUT]
Adjust the brightness of light source.
The setting is reected when it is already set with “Initial setting (operation setting)” (x page 43) in the [INITIAL
SETTING] screen or with the [PROJECTOR SETUP] menu → [OPERATION SETTING]. The [LIGHT OUTPUT]
setting is synchronized with the [PROJECTOR SETUP] menu → [OPERATION SETTING] → [LIGHT OUTPUT].
The most recent setting is reected in both items.
1) Press as to select [LIGHT OUTPUT].
2) Press qw to adjust.
Operation
Adjustment
Range of adjustment
Brightness Runtime (estimate)
Press w.
The screen becomes brighter. The runtime becomes shorter.
5.0 % - 100.0 %
Press q.
The screen becomes darker. The runtime becomes longer.
Note
f [LIGHT OUTPUT] can be adjusted individually for each setting item of [OPERATING MODE].
f In such a case when conguring multiple screens with multiple projectors, uniformity of brightness between multiple screens can be
obtained by adjusting [LIGHT OUTPUT].
[BRIGHTNESS CONTROL]
The projector is equipped with a brightness sensor to measure brightness and color of the light source, and
corrects brightness and white balance of the projected image according to the changes in brightness and color of
the light source.
By using this function, in such a condition that multiple screens are congured using multiple projectors, you can
reduce changes in overall brightness and white balance of the multiple screens due to aging of the light source
and suppress variation in brightness and white balance to preserve uniformity.
The setting is reected when it is already set with “Initial setting (operation setting)” (x page 43) in the [INITIAL
SETTING] screen or with the [PROJECTOR SETUP] menu → [OPERATION SETTING]. The [BRIGHTNESS
CONTROL SETUP] setting is synchronized with the [PROJECTOR SETUP] menu → [OPERATION SETTING] →
[BRIGHTNESS CONTROL SETUP]. The most recent setting is reected in both items.
Setting [BRIGHTNESS CONTROL SETUP]
Set the operation of the brightness control function.
1) Press as to select [BRIGHTNESS CONTROL].
2) Press the <ENTER> button.
f The [BRIGHTNESS CONTROL] screen is displayed.
3) Press as to select [BRIGHTNESS CONTROL SETUP].
4) Press the <ENTER> button.
f The [BRIGHTNESS CONTROL SETUP] screen is displayed.
5) Press as to select [CONSTANT MODE].
6) Press qw to switch the item.
f The items will switch each time you press the button.
[OFF] Does not correct the brightness of the screen by the brightness sensor.
[AUTO]
Corrects the brightness of the screen by the brightness sensor.
When the brightness of light source or white balance changes, the brightness of the projected image
is automatically corrected.
[PC]
Synchronizes nine or more projectors using a computer and the dedicated software “Multi Monitoring
& Control Software”
*1
.
*1 “Multi Monitoring & Control Software” is included in the supplied CD-ROM.
f Proceed to Step 9) when [PC] is selected.
7) Press as to select [LINK].
To Next Page
