Panasonic PT-RZ575

Chapter 4 Settings — [POSITION] menu
ENGLISH - 75
[PC-1]
*1
Performs screen adjustment using a computer.[PC-2]
*1
[PC-3]
*1
*1 Advanced skills are necessary to use a computer to control screen adjustment. Consult your dealer. Up to three screen adjustments
performed using the computer can be saved.
Setting [KEYSTONE] or [CURVED CORRECTION]
1) Press as to select [SCREEN ADJUSTMENT].
2) Press qw to select [KEYSTONE] or [CURVED CORRECTION].
3) Press the <ENTER> button.
f The [KEYSTONE] or [CURVED CORRECTION] screen is displayed.
4) Press as to select the item to adjust.
5) Press qw to adjust.
[KEYSTONE]
[LENS THROW RATIO]
The throw ratio of this projector is displayed.
[VERTICAL KEYSTONE]
[HORIZONTAL KEYSTONE]
[VERTICAL BALANCE] [HORIZONTAL BALANCE]
Adjust the setting according to the lens shift range in the vertical
direction.
Adjust the setting according to the lens shift range in the horizontal
direction.
[CURVED CORRECTION]
[LENS THROW RATIO]
The throw ratio of this projector is displayed.
[VERTICAL KEYSTONE]
[HORIZONTAL KEYSTONE]
[VERTICAL ARC] [HORIZONTAL ARC]
