3. Cooling Capacity of Indoor Unit
For MINI VRF SYSTEM
For MINI VRF SYSTEM
S-160MF2E5A
Power supply :220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) SHC : Sensible Heat Capacity (kW)
This data is when the indoor unit connects with 6HP outdoor unit.
RATING CAPACITY: 16.0 kW AIR FLOW RATE : 36.0 m
3
/min
EVAPORATOR
CONDENSER
AMBIENT TEMP. (°C)
AIR INTAKE. TEMP
W.B. D.B. 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 46
14
TC 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7
21 SHC
8.5 8.5 8.5 8.5 8.5 8.5 8.5 8.5 8.5 8.5 8.5 8.5 8.5 8.5 8.5 8.5
23 SHC 9.6 9.6 9.6 9.6 9.6 9.6 9.6 9.6 9.6 9.6 9.6 9.6 9.6 9.6 9.6 9.6
25 SHC 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7
27 SHC
10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7
15
TC 11.7 11.7 11.7 11.7 11.7 11.7 11.7 11.7 11.7 11.7 11.7 11.7 11.7 11.7 11.7 11.7
21 SHC
8.3 8.3 8.3 8.3 8.3 8.3 8.3 8.3 8.3 8.3 8.3 8.3 8.3 8.3 8.3 8.3
23 SHC 9.4 9.4 9.4 9.4 9.4 9.4 9.4 9.4 9.4 9.4 9.4 9.4 9.4 9.4 9.4 9.4
25 SHC 10.5 10.5 10.5 10.5 10.5 10.5 10.5 10.5 10.5 10.5 10.5 10.5 10.5 10.5 10.5 10.5
27 SHC
11.6 11.6 11.6 11.6 11.6 11.6 11.6 11.6 11.6 11.6 11.6 11.6 11.6 11.6 11.6 11.6
16
TC 12.8 12.8 12.8 12.8 12.8 12.8 12.8 12.8 12.8 12.8 12.8 12.8 12.8 12.8 12.8 12.8
21 SHC
8.1 8.1 8.1 8.1 8.1 8.1 8.1 8.1 8.1 8.1 8.1 8.1 8.1 8.1 8.1 8.1
23 SHC 9.2 9.2 9.2 9.2 9.2 9.2 9.2 9.2 9.2 9.2 9.2 9.2 9.2 9.2 9.2 9.2
25 SHC 10.3 10.3 10.3 10.3 10.3 10.3 10.3 10.3 10.3 10.3 10.3 10.3 10.3 10.3 10.3 10.3
27 SHC 11.4 11.4 11.4 11.4 11.4 11.4 11.4 11.4 11.4 11.4 11.4 11.4 11.4 11.4 11.4 11.4
29 SHC
12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5
17
TC 13.9 13.9 13.9 13.9 13.9 13.9 13.9 13.9 13.9 13.9 13.9 13.9 13.9 13.9 13.9 13.5
21 SHC
7.9 7.9 7.9 7.9 7.9 7.9 7.9 7.9 7.9 7.9 7.9 7.9 7.9 7.9 7.9 7.7
23 SHC 9.0 9.0 9.0 9.0 9.0 9.0 9.0 9.0 9.0 9.0 9.0 9.0 9.0 9.0 9.0 8.7
25 SHC 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 9.8
27 SHC 11.1 11.1 11.1 11.1 11.1 11.1 11.1 11.1 11.1 11.1 11.1 11.1 11.1 11.1 11.1 10.9
29 SHC
12.2 12.2 12.2 12.2 12.2 12.2 12.2 12.2 12.2 12.2 12.2 12.2 12.2 12.2 12.2 12.0
18
TC 14.9 14.9 14.9 14.9 14.9 14.9 14.9 14.9 14.9 14.9 14.9 14.9 14.9 14.9 14.6 13.5
21 SHC
7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.6 7.4 6.9
23 SHC 8.7 8.7 8.7 8.7 8.7 8.7 8.7 8.7 8.7 8.7 8.7 8.7 8.7 8.7 8.5 8.0
25 SHC 9.8 9.8 9.8 9.8 9.8 9.8 9.8 9.8 9.8 9.8 9.8 9.8 9.8 9.8 9.6 9.1
27 SHC 10.9 10.9 10.9 10.9 10.9 10.9 10.9 10.9 10.9 10.9 10.9 10.9 10.9 10.9 10.7 10.2
29 SHC 12.0 12.0 12.0 12.0 12.0 12.0 12.0 12.0 12.0 12.0 12.0 12.0 12.0 12.0 11.8 11.3
31 SHC
13.1 13.1 13.1 13.1 13.1 13.1 13.1 13.1 13.1 13.1 13.1 13.1 13.1 13.1 12.9 12.4
19
TC 16.0 16.0 16.0 16.0 16.0 16.0 16.0 16.0 16.0 16.0 16.0 16.0 16.0 15.8 14.6 13.5
21 SHC
7.3 7.3 7.3 7.3 7.3 7.3 7.3 7.3 7.3 7.3 7.3 7.3 7.3 7.2 6.6 6.1
23 SHC 8.4 8.4 8.4 8.4 8.4 8.4 8.4 8.4 8.4 8.4 8.4 8.4 8.4 8.3 7.7 7.2
25 SHC 9.5 9.5 9.5 9.5 9.5 9.5 9.5 9.5 9.5 9.5 9.5 9.5 9.5 9.4 8.8 8.3
27 SHC 10.6 10.6 10.6 10.6 10.6 10.6 10.6 10.6 10.6 10.6 10.6 10.6 10.6 10.4 9.9 9.4
29 SHC 11.6 11.6 11.6 11.6 11.6 11.6 11.6 11.6 11.6 11.6 11.6 11.6 11.6 11.6 11.0 10.5
31 SHC
12.8 12.8 12.8 12.8 12.8 12.8 12.8 12.8 12.8 12.8 12.8 12.8 12.8 12.7 12.1 11.6
20
TC 17.1 17.1 17.1 17.1 17.1 17.1 17.1 17.1 17.1 17.1 17.0 17.1 17.0 15.8 14.6 13.5
23 SHC
8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 7.4 6.9 6.5
25 SHC 9.1 9.1 9.1 9.1 9.1 9.1 9.1 9.1 9.1 9.1 9.1 9.1 9.1 8.5 8.0 7.6
27 SHC 10.2 10.2 10.2 10.2 10.2 10.2 10.2 10.2 10.2 10.2 10.2 10.2 10.2 9.6 9.1 8.6
29 SHC 11.3 11.3 11.3 11.3 11.3 11.3 11.3 11.3 11.3 11.3 11.3 11.3 11.3 10.7 10.2 9.7
31 SHC
12.4 12.4 12.4 12.4 12.4 12.4 12.4 12.4 12.4 12.4 12.4 12.4 12.4 11.8 11.3 10.9
21
TC 18.1 18.1 18.1 18.1 18.1 18.1 18.1 18.1 18.1 18.1 18.1 18.1 17.5 15.8 14.6 13.5
23 SHC
7.7 7.7 7.7 7.7 7.7 7.7 7.7 7.7 7.7 7.7 7.6 7.7 7.4 6.7 6.1 5.7
25 SHC 8.8 8.8 8.8 8.8 8.8 8.8 8.8 8.8 8.8 8.8 8.7 8.8 8.5 7.7 7.3 6.8
27 SHC 9.9 9.9 9.9 9.9 9.9 9.9 9.9 9.9 9.9 9.9 9.8 9.9 9.6 8.8 8.4 7.9
29 SHC 11.0 11.0 11.0 11.0 11.0 11.0 11.0 11.0 11.0 11.0 10.9 11.0 10.7 9.9 9.5 9.0
31 SHC
12.1 12.1 12.1 12.1 12.1 12.1 12.1 12.1 12.1 12.1 12.0 12.1 11.8 11.1 10.6 10.1
22
TC 19.2 19.2 19.2 19.2 19.2 19.2 19.2 19.2 19.2 19.2 19.1 18.7 18.0 15.8 14.6 13.5
25 SHC
8.4 8.4 8.4 8.4 8.4 8.4 8.4 8.4 8.4 8.4 8.4 8.1 7.8 6.9 6.5 6.0
27 SHC 9.5 9.5 9.5 9.5 9.5 9.5 9.5 9.5 9.5 9.5 9.4 9.3 9.0 8.0 7.6 7.2
29 SHC 10.6 10.6 10.6 10.6 10.6 10.6 10.6 10.6 10.6 10.6 10.6 10.4 10.1 9.1 8.7 8.3
31 SHC
11.7 11.7 11.7 11.7 11.7 11.7 11.7 11.7 11.7 11.7 11.7 11.5 11.2 10.3 9.8 9.4
23
TC 20.3 20.3 20.3 20.3 20.3 20.3 20.3 20.3 20.3 20.3 19.8 19.1 18.1 15.8 14.6 13.5
25 SHC
8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 7.8 7.5 7.1 6.2 5.7 5.3
27 SHC 9.1 9.1 9.1 9.1 9.1 9.1 9.1 9.1 9.1 9.1 8.9 8.6 8.2 7.3 6.8 6.4
29 SHC 10.2 10.2 10.2 10.2 10.2 10.2 10.2 10.2 10.2 10.2 10.0 9.7 9.3 8.4 7.9 7.5
31 SHC
11.3 11.3 11.3 11.3 11.3 11.3 11.3 11.3 11.3 11.3 11.1 10.8 10.4 9.5 9.0 8.6
