Panasonic S-36MK2E5A - Flap Setting for each Indoor Unit; Flap Setting for each Air Outlet

3-8
Control of VRF SYSTEM
1
2
3
4
5
6
7
8
9
1. Operating Instructions
12
(EN)
Flap Setting for Each Indoor Unit
FLAP
When setting À aps for each indoor unit • Flaps of all air outlets of 1 indoor unit face the same
direction.
1
Display the menu screen.
 To return to the previous screen
Press .
 To return to the top screen
Press 2 times.
2
Select [FLAP]. Ÿ ź ĺ
3
Select the indoor unit to set. Ÿ ź ĺ Ź • ALL: All units connected to the remote
controller
e.g. (unit) ALL ĺ 1-1 ĺ 1-2 to 1-8
4
Select the À ap direction. Ÿ ź ĺ
(Press 2 times to ¿ nish.)
• Pressing Ÿ or ź during swing
can stop the À ap at your
preferred position.
• Pressing Ÿ or ź while swing is stopped
sets the À ap at the speci¿ ed position.
When Ÿ is pressed
When ź is pressed
• 3-level adjustment is possible for Cool
and Dry mode.
Swing
e.g. unit 1-1 e.g. unit 1-3
13
(EN)
Flap Setting for Each Air Outlet
Lock indiv. À ap
When setting the À ap for each air outlet individually according to the room condition • Even if the À ap setting of all indoor units (P.9) or each indoor unit (P. 12) is
changed, the À ap directions set here are not changed.
1
Display the menu screen.
 To return to the previous screen
Press .
 To return to the top screen
Press 2 times.
2
Select [Lock indiv. À ap]
Ÿ ź ĺ
3
Select the indoor unit to set. Ÿ ź ĺ Ź e.g. 1-1 ĺ 1-2 to 1-8
4
Select the air outlet. Ÿ ź ĺ Ź • The air outlet No. changes according to
the installation direction. Check by actual operation.
1
2
3
4
5
Select the À ap direction. Ÿ ź ĺ
(Press 2 times to ¿ nish.)
• Although
is also displayed in
Cool and Dry mode, the actual direction is
.
* For types other than the 4-way cassette
type, the following display appears and this function cannot be used.
Swing
Unlock
