2-36
Design of VRF SYSTEM
1
2
3
4
5
6
7
8
9
3. How to install the indoor unit
CAUTION
The indoor unit should be slightly tilted downward toward the drain pipe connection side as shown in figure below
so that the wastewater can flow smoothly without being trapped in the middle. (Fig. 2-80)
Ceiling
Approx. 1°
Approx. 2°
Ceiling
Diagonally right down (front view)
(Ex.: Diagonal-right-backwards)
Diagonally backward (side view)
Fig. 2-80
