Ref. No. Part No. Part Name & Description Remarks
351 RMM0242 TRV SLIDE PLATE (R) [M]
352 RMM0243 SELECT RACK PART [M]
353 RMM0244 SELECT GUIDE [M]
354 RMQ1051 PITCH PLATE PART [M]
355 RMQ1052 UD BASE [M]
356 RMQ1056 TRAY GUIDE [L] [M]
357 RMQ1057 TRAY GUIDE [R] [M]
358 RMQ1058 GEAR HOLDER [M]
359 RMQ1059 TOP COVER [M]
360 RMQ1060 CLAMP GUIDE [M]
361 RMQ1061 TG.PLATE [M]
362 RMR0334 FIXTURE [M]
363 RMR0624-W5 CLAMPER [M]
364 RMR1407A-H1 TRAY [M]
365 RMR1407B-H1 TRAY [M]
366 RMR1407C-H1 TRAY [M]
367 RMR1407D-H1 TRAY [M]
368 RMR1407E-H1 TRAY [M]
369 RFKNAPM77MDS MECHA BASE ASS’Y [M]
370 RMR1427-X MIDDLE CHASSIS [M]
371 RMS0757-1 FIXED PIN [M]
375 RMS0762 TRAY GEAR SHAFT [M]
376 RXG0053 TRAY DRIVE GEAR ASSY [M]
377 RXQ0999 OPU UNIT [M]
378 RXQ0803 LOADING MOTOR ASS’Y [M]
379 RXQ0804 UD MOTOR ASS’Y [M]
380 XTB3+10J SCREW [M]
381 XTN2+6G SCREW [M]
382 RMC0472 TRAY SPRING [M]
383 XTBS26+8J SCREW [M]
22.3. Cabinet
22.3.1. Cabinet Parts Location
106
