Panasonic SA-PM19E - Block Diagram; Notes of Schematic Diagram

2. Set the function to “TAPE” position.
3. Insert a normal blank cassette tape (QZZCRA) and press “REC”
mode on main unit.
4. Check that the output frequency is within the standard range.
Standard Value: 98
±8 kHz
Fig. 13
14. Block Diagram
14.1. CD Servo Block
14.2. Main Block
15. Notes of Schematic Diagram
(All schematic diagrams may be modified at any time with the development of new technology)
Note :
S1
Stock switch
S2
Play switch
S3
Bottom switch
S4
Open switch
83
