Ref. No. Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 REEV0025 24FFC (PANEL-MAIN) [M]
2 REEV0026 21P FFC (DECK PCB) [M]
3 REEX0166 14P FFC WIRE [M]
4 REEV0039 17P FFC (CR16-MAIN) [M]
5 REM0094A COOLING FAN [M]
6 RFKLAPM19PCS CD LID ASS’Y [M]
7 RFKGAPM19EBS FRONT PANEL ASS’Y [M]
7-1 RGPV0021A-Q FL WINDOW [M]
8 RGKV0043-S CENTER ORNAMENT [M]
9 RGLV0011 AC IN LIGHTING TIP [M]
10 RKSX0056K-H REAR PANEL [M]EG E
10 RKSX0056L-H REAR PANEL [M]EB
11 RGU2280-S CASS EJECT BUTTON [M]
12 RGU2281-1S FAMILY BUTTON A [M]
13 RGUV0040-S SSEQ BUTTON [M]
14 RGUV0064-S FF BUTTON [M]
15 RGUV0066-S FAMILY BUTTON B [M]
16 RGW0406-S VOLUME KNOB [M]
17 RHD30007-1SJ SCREW [M]
18 RHGV0008 LEG CUSHION [M]
19 RKF0688-S CASS HOLDER/LID [M]
20 RKM0502-1S SIDE PANEL L [M]
21 RKM0503-1S SIDE PANEL R [M]
22 RKM0504B-S TOP PANEL [M]
23 RMB0448-J LOCK ROD SPRING [M]
24 RMB0780 CASS OPEN SPRING [M]
25 RMB0783 CD LID OPEN SPRING [M]
26 RMK0595 BOTTOM CHASSIS [M]
27 RMKX0090 INNER CHASSIS [M]
28 RMM0163-1 CASS LOCK ROD [M]
29 RMN0780 CD LID SUPPORT [M]
30 RMNV0014 FL HOLDER [M]
31 RMY0260 HEAT SINK [M]
32 RSCV0019 REAR SHIELD PLATE [M]
33 RSCV0023 FL SHIELD PLATE [M]
34 RUS757ZAA CASS HALF SPRING [M]
35 RXGX0003 DAMPER GEAR [M]
36 RXXX0043 HEAT SINK UNIT [M]
37 XTB3+10JFZ SCREW [M]
38 XTB3+8JFZ SCREW [M]
39 XTBS26+10J SCREW [M]
42 XTV3+10G SCREW [M]
43 XTW3+15T SCREW [M]
44 XTWS26+10Q SCREW [M]
45 XTWS3+6T SCREW [M]
46 RHGV0010 FL CUSHION [M]
22.4. Electrical Part List
