Ref. No. Part No. Part Name & Description Remarks
PRINTED CIRCUIT BOARD
REPV0016B DECK P.C.B. / TAPE EJECT P.C.B. [M] / (RTL)
REPV0017B MAIN P.C.B./ SPEAKER TERMINAL P.C.B. / TACT SWITCH P.C.B. /
SWITCH P.C.B. / PANEL P.C.B. / HEADPHONE P.C.B. /
[M] / (RTL)
REPV0018B POWER P.C.B. / TRANSFORMER P.C.B. [M]E/EG / (RTL)
REPV0018C POWER P.C.B. / TRANSFORMER P.C.B. [M] EB / (RTL)
REPX0321H DECK MECHANISM P.C.B. [M] / (RTL)
REP3569A CD LOADING P.C.B. [M] / (RTL)
REPV0010A CD SERVO P.C.B. [M] / (RTL)
INTEGRATED CIRCUITS
IC11 C0GAG0000007 IC DRIVER [M]
IC21 C0GAG0000007 IC DRIVER [M]
IC300 C1BB00000757 IC ASP [M]
IC302 C2CBJF000016 IC MICRO PROCESSOR [M]
IC304 C1BB00000715 IC RDS [M]
IC500 RSN314H41A-P IC POWER AMP HIC [M]
IC501 C0AABB000125 IC OP AMP [M]
IC503 C0CAABE00006 IC 3.3V REGULATOR [M]
IC600 C0HBB0000039 IC FL DRIVER [M]
IC701 AN22004A-NF IC HEAD AMP [M]
IC702 MN6627934CH IC LSI [M]
IC703 BA5948FPE2 IC 4 CH DRIVE [M]
IC704 C3ABMB000027 IC 16M DRAM [M]
IC971 CNB13030R2AU IC PHOTO INTERUPTOR [M]
IC1000 C1AA00000612 IC ANALOG SW [M]
IC1001 AN7326K IC DECK R/P [M]
TRANSISTORS
Q1 B3NAA0000068 TRANSISTOR [M]
Q200 KRA102STA TRANSISTOR [M]
Q201 KTC3875GRTA TRANSISTOR [M]
Q222 KTC3875GRTA TRANSISTOR [M]
Q223 KTC3875GRTA TRANSISTOR [M]
Q224 KTC3875GRTA TRANSISTOR [M]
Q301 KTA1504GRTA TRANSISTOR [M]
Q302 KRC102STA TRANSISTOR [M]
Q303 KTA1504GRTA TRANSISTOR [M]
Q304 B1GBCFGG0001 TRANSISTOR [M]
Q305 B1GBCFGG0001 TRANSISTOR [M]
Q306 KRC103STA TRANSISTOR [M]
Q307 KTC3875GRTA TRANSISTOR [M]
Q308 KTC3875GRTA TRANSISTOR [M]
Q309 KRC101STA TRANSISTOR [M]
Q310 KRC101STA TRANSISTOR [M]
Q400 KRA102STA TRANSISTOR [M]
Q422 KTC3875GRTA TRANSISTOR [M]
Q423 KTC3875GRTA TRANSISTOR [M]
Q424 KTC3875GRTA TRANSISTOR [M]
Q501 KTC2026 TRANSISTOR [M]
Q502 KTA1046 TRANSISTOR [M]
