Panasonic SA-PM19E - Page 115

Ref. No. Part No. Part Name & Description Remarks
CP1301 RJS1A6805-J CONNECTOR [M]
CP1902 K1KA09B00058 9P CONNECTOR [M]
CS971 RJU071H09M1 CONNECTOR [M]
COILS & TRANSFORMERS
L200 G0AR76Y00001 COIL [M]
L201 G0AR76Y00001 COIL [M]
L203 J0JBC0000019 CHIP INDUCTOR [M]
L204 G0C3R3JA0027 COIL [M]
L300 G0C3R3JA0027 COIL [M]
L301 G0A200D00002 RF CHOKE COIL [M]
L302 G0C101JA0030 COIL [M]
L303 G0C101JA0030 COIL [M]
L400 G0AR76Y00001 COIL [M]
L401 G0AR76Y00001 COIL [M]
L503 RLQZ371 CHOKE COIL
[M]
L600 RLQB101JTD-D INDUCTOR [M]
L601 RLQB101JTD-D INDUCTOR [M]
L602 G0C100JA0030 INDUCTOR [M]
L603 G0C101JA0027 COIL [M]
L604 G0C3R3JA0027 COIL [M]
L1301 7L1A62N BIAS OCS COIL [M]
L1302 RLQB470JTD-D RF CHOKE COIL [M]EG E
T501 G4C6BDZ00002 TRANSFORMER
[M]
T502 G4C2AAJ00006 BACKUP TRANSFORMER
[M]
COMPONENT COMBINATION
Z301 ENG07802QF TUNER PACK [M]
Z501 ERZV10V511CS ZENER
[M]
Z601 B3MAZ0000023 REMOTE CONTROL SENSOR [M]
RELAY
RL501 K6B1ADA00011 RELAY
[M]
OSCILLATORS
X300 H0H433400001 CRYSTAL OSCILLATOR [M]
X301 H2A100500006 RESONATOR [M]
X302 RSXD32K7S02 CRYSTAL OSCILLATOR [M]
X701 RSXC16M9S04 CRYSTAL OSCILLATOR [M]
DISPLAY TUBE
FL600 A2BB00000131 FL DISPLAY [M]
FUSE
F1 K5Y630B00001 FUSE
[M]
