Panasonic SA-PM19E - Page 88

Pin No. Mark I/O Function
13 BDO O BDO output terminal
14 OFTR O OFTR output terminal
15 /RFDET O NRFDET output terminal
16 LDON - LDON terminal
17 GND - Earth terminal
18 EQBST - Equalizer boost
adjustment terminal
19 VREF O VREF output terminal
20 TEN I Amp inverting input
terminal
21 TEOUT O TE amp output terminal
22 FEN I Amp inverting input
terminal
23 FEOUT O FE amp output terminal
24 GCTL - GCTL terminal
25 FBAL I FBAL control terminal
26 TBAL I TBAL control terminal
27 E O Tracking signal input
terminal 1
28 F O Tracking signal input
terminal 2
29 D O Tracking signal input
terminal 4
30 B O Tracking signal input
terminal 2
31 C O Tracking signal input
terminal 3
32 A O Tracking signal input
terminal 1
20.2. IC702 (MN6627934CH) IC LSI
88
