Panasonic SA-PM19E - Page 90

Pin No. Mark I/O Function
32 FE I Focus error signal input
(analog input)
33 TE I Tracking error signal
input (analog input)
34 RFENV I RF envelope signal input
(analog input)
35 OFT I Off track signal input (H:
off track)
36
NRFDET
I RF detective signal input
(L: detection)
37 BDO I Drop out signal input (H:
drop out)
38 LDON O Laser ON signal input (H:
ON)
39 ARF I RF signal input
40 IREF I/O Resistance terminal for
current electricity setting
41
ADPVCC
I Analog power supply
voltage monitor input
42 DSLF I/O DSL loop filter terminal
43 RFSW I/O DSL loop filter terminal
44 PLLF I/O PLL loop filter terminal
(phase comparison)
45 PLLFO I/O PLL loop filter terminal
(speed comparison)
46 AVDD2 - ”Analog power supply
47 AVSS2 - ”Analog ground
48 OUTL O L ch audio output
49 AVSS1 - Analog ground (audio
output)
50 OUTR O R ch audio output
51 AVDD1 - Analog power supply
(audio output)
52 DVSS3 - Digital GND
53 DVDD3 - Digital power supply
54 IOVDD2 - IO power supply
55 FLAG O Flag output
56 EXT2 I/O Extension input-output
port 2
57 EXT0 I/O Extension input-output
port 0
58 EXT1 I/O Extension input-output
port 1
90
