Ref. No. Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 REEX0202 10P FFC [M]
2 REEX0391 19P FFC WIRE [M]
3 REEX0211 14P FFC WIRE [M]
4 REEX0212 14P FFC WIRE [M]
5 REEX0215 30P FFC [M]
6 REEX0291 17P FFC (PANEL-MAIN) [M]
7 REM0072-4 FAN [M]
8 RYQX0093-S CD LID UNIT [M]
9 RGKX0209B-V TOP ORNAMENT [M]
10 RGKX0211-2S CONTROL PANEL [M]
11 RGLX0069-Q POWER LIGHT CHIP [M]
12 RGPX0110C-S FRONT PANEL [M]
13 RGRX0023Q-AA REAR PANEL [M]
14 RGUX0527-S POWER BUTTON [M]
15 RGUX0528-S DECK 1/2 CONTROL BTN [M]
16 RGUX0529-S CONTROL BUTTON (L) [M]
17 RGUX0530-S CONTROL BUTTON (R) [M]
18 RGUX0531A-1S FUNCTION BUTTON (L) [M]
19 RGUX0532C-1S FUNCTION BUTTON (R) [M]
20 RGUX0533-S PRESET EQ BUTTON [M]
21 RGUX0534A-Q SS EQ BUTTON [M]
22 RGUX0535-S CD EJECT BUTTON [M]
23 RGUX0536-S 5 CD CONTROL BUTTON [M]
24 RGWX0056-S MIC VOL KNOB [M]
25 RGWX0080-S VOLUME KNOB [M]
Ref. No. Part No. Part Name & Description Remarks
INTEGRATED CIRCUITS
REPX0437B CD SERVO P.C.B. (SIDE A &
B)
[M](RTL)
REPX0439B MAIN P.C.B [M](RTL)
REPX0382D PANEL P.C.B [M](RTL)
REPX0382D TACT SWITCH P.C.B [M](RTL)
REPX0331A DECK P.C.B [M](RTL)
REPX0321B DECK MECHANISM P.C.B [M](RTL)
REPX0440B POWER P.C.B [M](RTL)
REPX0327M TRANSFORMER P.C.B [M](RTL)
REP2578A-N CD LOADING P.C.B [M](RTL)
REP2578A-N CD DETECT P.C.B [M](RTL)
REP2578A-N SPINDLE POSITION P.C.B [M](RTL)
REPX0343B VCD P.C.B (SIDE A & B) [M](RTL)
INTEGRATED CIRCUITS
IC1 C0GAM0000005 IC MOTOR DRIVE [M]
IC600 C2BBGF000579 IC MICROPROCESSOR [M]
IC601 C1BB00000574 IC I/O EXPANDER [M]
IC603 C1BB00000086 IC SPECTRUM ANALYSER [M]
IC900 C1BB00000716 IC ECHO [M]
IC951 CNB13030R2AU IC PHOTO INTERRUPTER [M]
IC971 CNB13030R2AU IC PHOTO INTERRUPTER [M]
IC1001 AN7348S-E1 IC P.B EQ/REC AMP/ ALC/TPS
AMP
[M]
IC1004 C1AA00000612 IC R/P SELECT [M]
IC1101 LA1833NMNTLM IC FM/AM IF AMP/ DET/AM OSC
MIX/ FM MPX
[M]
IC1102 LC72131MDTRM IC PLL FREQUENCY
SYNTHESIZER
[M]
IC2100 C3ABMG000160 IC 16M DRAM [M]
IC2120 C3FBJC000057 IC FLASH ROM [M]
IC2300 C1AB00001854 IC DSP [M]
IC2350 C1AB00001855 IC VCD AUDIO/VIDEO DECODER [M]
IC2360 C0ABBB000126 IC OP-AMP [M]
IC2700 C0CBCAA00003 IC 2.8V REGULATOR [M]
IC2801 MN101C30AEB IC MECHACON [M]
IC2802 C0JBAZ001229 IC 3V - 5V LEVEL SHIFT [M]
IC2804 C0DAAHG00007 IC REGULATOR [M]
IC2900 C1BB00000747 IC ASP [M]
Ref. No. Part No. Part Name & Description Remarks
26 RHD30004-2S SCREW [M]
27 RKA0059-K LEG RUBBER [M]
28 RKFX0093-K CASS. HOLDER (L) [M]
29 RKFX0094-K CASS. HOLDER (R) [M]
30 RKMX0077-S TOP CABINET (BENT) [M]
31 RKWX0210-V FL WINDOW [M]
32 RKWX0216-1 FL FILTER [M]
33 RMA1110-2 TRAY ANGLE [M]
34 RMBX0021 CASS OPEN SPRING [M]
35 RMCX0021 TRANSISTOR CLIP [M]
36 RMKX0064-1 BOTTOM CHASSIS [M]
37 RMKX0066-1L CD CHASSIS [M]
38 RMNX0019 PCB SPACER [M]
39 RMNX0079 FL HOLDER [M]
40 RUS757ZAA CASS HALF SPRING [M]
41 RXGX0002 DAMPER GEAR [M]
42 RXXX0039A HEAT SINK UNIT [M]
43 RYFX0127-S CASS LID UNIT (L) [M]
44 RYFX0128-S CASS LID UNIT (R) [M]
45 SHE187-5J PCB SUPPORT [M]
46 XTB3+10JFZ SCREW [M]
47 XTB3+20J SCREW [M]
48 XTBS26+10J SCREW [M]
49 XTBS3+8JFZ1 SCREW [M]
50 XTW3+12T SCREW [M]
51 XTW3+15T SCREW [M]
Ref. No. Part No. Part Name & Description Remarks
IC2901 C0AABB000117 IC HEADPHONE AMP [M]
IC2903 KIA4558FEL IC DUAL OP AMP [M]
IC5801 RSN315H42B-P IC POWER HIC [M]
IC7001 AN22004A-NF IC SERVO AMP [M]
IC7002 MN662790RSC IC SERVO PROCESSOR/ DIGITAL
SIGNAL PROCESSOR/ DIGITAL
FILTER/ D/A CONVERTER
[M]
IC7003 AN8739SBTE2 IC FOCUS COIL/ TRACKING
COIL/ TRAVERSE MOTOR/
SPINDLE MOTOR DRIVE
[M]
TRANSISTORS
Q1 B1GACFGG0004 TRANSISTOR [M]
Q600 B1GACFLL0007 TRANSISTOR [M]
Q603 B1ACCF000063 TRANSISTOR [M]
Q604 B1ACCF000063 TRANSISTOR [M]
Q605 KRC102MTA TRANSISTOR [M]
Q606 KTC3199GRTA TRANSISTOR [M]
Q607 2SC1740SSTA TRANSISTOR [M]
Q608 B1GCCFJJ0015 TRANSISTOR [M]
Q609 B1GCCFJJ0015 TRANSISTOR [M]
Q610 KTC3199GRTA TRANSISTOR [M]
Q611 KTC3199GRTA TRANSISTOR [M]
Q612 KTC3199GRTA TRANSISTOR [M]
Q613 KTC3199GRTA TRANSISTOR [M]
Q614 KTA12710YTA TRANSISTOR [M]
Q615 KTA12710YTA TRANSISTOR [M]
Q900 2SC1740SSTA TRANSISTOR [M]
Q950 B1BACD000017 TRANSISTOR [M]
Q951 2SB621ARSTA TRANSISTOR [M]
Q952 KRC102MTA TRANSISTOR [M]
Q953 B1AAGC000007 TRANSISTOR [M]
Q954 B1AAGC000007 TRANSISTOR [M]
Q1001 B1ABCF000131 TRANSISTOR [M]
Q1003 B1AAGC000007 TRANSISTOR [M]
Q1004 B1AAGC000007 TRANSISTOR [M]
Q1005 B1AAGC000007 TRANSISTOR [M]
Q1007 B1ABCF000131 TRANSISTOR [M]
Q1012 B1ABEB000001 TRANSISTOR [M]
Q1013 B1ABEB000001 TRANSISTOR [M]
Q1014 B1ABCF000011 TRANSISTOR [M]
22.3.2. Cabinet Parts List
22.4. Electrical Parts List
104
SA-VK31EE
