11 Description of Error Code
11.1. Abnormality Detection for DECK Mechanism
No. Error Error Display Problem condition
1 MODE SW abnormal H01 Normal operation during mecha transition, MODE SW abnormal is
memorized. The content of abnormality can be confirmed in the
abnormal detection mode explained in the later section.
2 REC INH SW abnormal H02 The content of abnormality can be confirmed in the abnormal detection
mode explained in the later section.
3 HALF SW abnormal H03
4 abnormal F01
11.2. Abnormality detection for CD/Changer Block
No. Error Error Display Problem condition
1 REST SW abnormal F15 Under normal operation (Self-Diagnostic Mode inclusive), this error
occurs when the RESTSW ON is not detected within the specified time
and shall be memorized.
2 Transmission error between CD servo
LSI and micon
F26 Under normal operation (Self-Diagnostic mode inclusive), this error occurs
when the selection is set to CD and SENSE=”H” is detected and
SENSE=”L” is not detected within a fail safe time (20ms) after system
command transmission was sent.
3 CLAMP SW abnormal F16 Refer to CR20 control specification section 5-2 [ERROR CODE] table M-
0A error is detected.
4 BOTTOM SW abnormal F17 Refer to CR20 control specification section 5-2 [ERROR CODE] table M-09
error is detected.
5 POSITION SW abnormal F27 Refer to CR20 control specification section 5-2 [ERROR CODE] table M-05
~ M-08 error is detected.
6 SW1 abnormal F28 Refer to CR20 control specification section 5-2 [ERROR CODE] table M-02
~ M-08 error is detected.
7 SW2 abnormal F29
8 OPEN SW abnormal H15 Refer to CR20 control specification section 5-2 [ERROR CODE] table M-01
error is detected.
11.3. Power Supply Related Error Detection
No. Error Error Display Problem condition
1 POWER AMP output abnormal F61 During normal operation, if DCDET 1/2 becomes “L”, normal POWER
OFF process shall not ve executed, PCNT shall be switched to “L”
immediately. GOODBYE shall not be displayed and the error display F61
will be displayed instead.
2 seconds after the F61 display, ECONO shall be set to “L” and FL
display shall be turned off.
The error content shall be memorized when the abnormality occurs and
can be displayed in the C-mecha self-diagnostic mode described later.
