19.2. Electrical Replacement List
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
F902 K5D312BL0008 FUSE 1
F900.90
1
K5D802BNA003 FUSE 2
C11 K1MN50BA0016 50P CONNECTOR 1
C12 K1MN20B00043 20P CONNECTOR 1
C21 K1MN50BA0016 50P CONNECTOR 1
C22 K1MN20B00043 20P CONNECTOR 1
C23 K1KA11A00102 11P CONNECTOR 1
C24 K1KA08A00232 8P CONNECTOR 1
C802 EEUFC1E471 E 470UF, 25V 1
C803 EEUFC1E331 E 330UF, 25V 1
C805 EEUFC1C102 E 1000UF, 16V 1
C806 EEUFC1A102 E 1000UF, 10V 1
C807 ECJ2VF1H104Z C 0.1UF, Z, 50V 1
C808,09 ECQB1H103JF P 0.01UF, J, 50V 2
C810 EEUFC1E561 E 560UF, 25V 1
C811 ECQB1H103JF P 0.01UF, J, 50V 1
C812 ECQB1H104JF P 0.1UF, J, 50V 1
C813 ECQB1H473JF P 0.047UF, J, 50V 1
C814 EEUFC0J152 E 1500UF, 6.3V 1
C815 ECQB1H104JF P 0.1UF, J, 50V 1
C816 ECQB1H682JF3 P 6800PF, J, 50V 1
C901 ECQU2A105BN9 P 1UF, 250V 1
C902,03 ECKCNA221KB7 C 220PF, M, 2
C904 ECQU2A474BN9 P 0.47UF, 250V 1
C905 ECQU2A105BN9 P 1UF, 250V 1
C906,07 ECKCNA221KB7 C 220PF, M, 2
C910 EETHC2W101J C 4700PF, Z,450V 1
C911 ECQE6223KF P 0.022UF, K,400V 1
C912 EEUEB1H100SB E 100UF, 25V 1
C913 ECJ2XC1H221J C 220PF, J, 50V 1
C914 ECKD3D221KBN C 220PF, K, 2KV 1
C915 ECJ2XC1H471J C 470PF, J, 50V 1
C916 ECJ2VF1H103Z C 0.01UF, Z, 50V 1
C917 EEUEB1H100SB E 100UF, 25V 1
C918 ECJ2XC1H222J C 2200PF, J, 50V 1
C919 ECJ2XF1H224Z C 0.22UF, Z, 50V 1
C920 ECKDNA471KB7 C 470PF, Z, 1
C930 EEUFC1E222 E 2200UF, 25V 1
C931 ECKD3A331KBP C 330PF, K, 1KV 1
C932 EEUEB1E101 E 100UF, 25V 1
C933 ECJ2FB1E105K C 1UF, K, 16V 1
C1530 ECJ3XB0J106M C 10UF, M,6.3V 1
C2312 ECJ2VF1H103Z C 0.01UF, Z, 50V 1
C2313 ECA1HHG470 E 47UF, 50V 1
C2314 ECA1EHG470 E 47UF, 25V 1
C2350,5
1
TCUY1C225KBM C 2.2UF, 16V 2
C2352,5
3
ECA1HHG100 E 10UF, 50V 2
C2354,5
5
ECA1VM470 E 47UF, 35V 2
C2356,5
7
ECJ2XB1H102K C 1000PF, K, 50V 2
C2358,5
9
ECA1HM2R2 E 2.2UF, 50V 2
C2360,6
1
ECJ2XC1H102J C 1000PF, J, 50V 2
C2362,6
3
ECA1EM471 E 470UF, 25V 2
C2364,6
5
ECQV1H104JM P 0.1UF, J, 50V 2
C2366,6
7
ECQV1H225JM P 2.2UF, J, 50V 2
C2368,6
9
ECQV1H104JM P 0.1UF, J, 50V 2
C2370 ECA1VM470 E 47UF, 35V 1
C2419 ECA1HHG100 E 10UF, 50V 1
C2423 ECJ2XB1H103K C 0.01UF, K, 50V 1
C2426 ECJ2XB1H153K C 0.015UF, K, 50V 1
C2427 ECA1HHG100 E 10UF, 50V 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
C2429 EEAGA1C101 E 100UF, 16V 1
C2431 ECJ2VF1H103Z C 0.01UF, Z, 50V 1
C2433 ECJ2XB1H393K C 0.039UF, K, 50V 1
C2434 ECJ2XB1H223K C 0.022UF, K, 50V 1
C2435 ECJ2XB1H103K C 0.01UF, K, 50V 1
C2436 ECJ3VB1C104K C 0.10UF, K, 16V 1
C2437,3
8
EEAGA1C101 E 100UF, 16V 2
C2440,4
1
ECJ3XF1C475Z C4.7UF,Z,16V 2
C2450 ECA1HHG100 E 10UF, 50V 1
C2451 ECA1HHG4R7 E 4.7UF, 50V 1
C2452 ECJ2XB1H562K C 5600PF, K, 50V 1
C2453 ECJ2VF1H104Z C0.1UF,Z,50V 1
C2454 ECA1HHG4R7 E 4.7UF, 50V 1
C2457 ECA1HHG4R7 E 4.7UF, 50V 1
C2458 ECJ2XC1H102J C 1000PF, J, 50V 1
C2459 ECJ3VB1C104K C 0.10UF, K, 16V 1
C2460 ECJ2XB1H473K C 0.047UF, K, 50V 1
C2461 ECJ2XC1H102J C 1000PF, J, 50V 1
C2463 ECJ2XB1H473K C 0.047UF, K, 50V 1
C2466,6
7
ECJ3VB1C104K C 0.10UF, K, 16V 2
C3001 ECJ1VF1H103Z C 0.01UF, Z, 50V 1
C3002
02
ECJ2XB1E104K C0.1UF,K,25V 1 HA
C3002 ECJ3XF1C475Z C4.7UF,Z,16V 1
C3003 EEVHP1A100 E 10UF, 10V 1
C3004 EEEHB1C470P C 47PF, J, 16V 1
C3004
02
EEVHP1A100 E 10UF, 10V 1 HA
C3005
02
ECJ1XB1C104K C0.1UF,Z,16V 1 HA
C3005 ECJ2XB1H682K C 6800PF, K, 50V 1
C3006
02
ECJ1XB1C104K C0.1UF,Z,16V 1 HA
C3006 ECJ2XB1H682K C 6800PF, K, 50V 1
C3007
03
ECJ1XB1C104K C0.1UF,Z,16V 1 HA
C3007
02
ECJ2XB1H682K C 6800PF, K, 50V 1 HB
C3007 EEEHB1C470P C 47PF, J, 16V 1
C3008 ECJ1VF1H104Z C0.1UF,Z,50V 1
C3008
03
ECJ1XB1C104K C0.1UF,Z,16V 1 HA
C3008
02
ECJ2XB1H682K C 6800PF, K, 50V 1 HB
C3009 ECJ1XB1C104K C0.1UF,Z,16V 1
C3009
02
EEVHB1C470 E 47UF, 16V 1 HA
C3010 ECJ1XB1C104K C0.1UF,Z,16V 1
C3011 ECJ1XB1C104K C0.1UF,Z,16V 1
C3011
03
ECJ1XB1C104K C0.1UF,Z,16V 1 HA
C3011
02
EEVHB1C470 E 47UF, 16V 1 HB
C3012 ECJ1VF1H103Z C 0.01UF, Z, 50V 1
C3012
03
ECJ1XB1C104K C0.1UF,Z,16V 1 HA
C3012
02
ECJ2VF1C104Z C0.1UF,Z,16V 1 HB
C3013 ECJ1VF1H103Z C 0.01UF, Z, 50V 1
C3013
02
ECJ2XB1H682K C 6800PF, K, 50V 1 HB
C3014 ECJ1VF1H103Z C 0.01UF, Z, 50V 1
C3014
02
EEVHB1C470 E 47UF, 16V 1 HB
C3015 ECJ1VF1H103Z C 0.01UF, Z, 50V 1
C3015
02
ECJ1XC1H470J C 47PF, J, 50V 1 HB
C3016 ECJ1VF1H103Z C 0.01UF, Z, 50V 1
C3016
02
ECJ1XC1H220J C 22PF, J, 50V 1 HB
C3017 ECJ1VF1H103Z C 0.01UF, Z, 50V 1
C3017
02
ECJ1XC1H680J C 68PF, J, 50V 1 HB
C3018 EEEHB1C470P C 47PF, J, 16V 1
