5 PCB Structure sheet of GP7D chassis
Board Name Function Remarks
D Digital Signal Processor 1
J Slot Interface & SYNC processor 1
Z Audio out, DC-DC converter
SS Sustain Out 1
SC Scan out 1
SU Sustain connection (Upper) 1
SD Sustain connection (Lower) 1
C1 Data Drive (Lower Right)
C2 Data Drive (Lower Left)
H3 Speaker terminal
S1 Power switch
SS2 Sustain connection (Upper)
SS3 Sustain connection (Lower)
V1 Front SW. & Remote receiver
PF Line filter
P Power supply 1
HX PC_type_Input terminal
HB BNC Composite/Component Video 2
HA BNC Component Video 2
Remarks
1. Recommend PCB´s for initial service for GP7D chassis.
2. For System model except BK, BS, EK, ES model
9
TH-37PW7BX
