Panasonic TH-37PW7BX - Page 38

TH-37PW7BX/EX
TH-37PWD7BK/EK/UY
TH-42PW7BX/EX
TH-42PWD7BK/BS/EK/ES/UY
P-BOARD TNPA3213AB
TH-37PW7BX/EX
TH-37PWD7BK/EK/UY
TH-42PW7BX/EX
TH-42PWD7BK/BS/EK/ES/UY
P-BOARD TNPA3213AB
Parts Location
P-BOARD (FOIL SIDE)
IC
IC401 H-3
IC402 H-3
IC403 H-3
IC404 H-3
IC406 F-2
IC408 G-3
IC409 G-3
IC501 H-5
IC502 H-5
IC503 H-4
IC504 H-4
IC511 G-5
IC512 F-6
IC520 G-4
IC521 B-3
IC522 B-3
IC523 G-4
TP2 D-3
TP3 D-3
TP4 D-3
TP5 E-2
TP6 E-2
TP7 E-2
TP8 E-2
TP9 C-6
TP10 C-6
TP10 D-2
TP11 C-6
TP12 C-6
TP13 F-4
Q401 F-1
Q403 G-3
Q404 D-2
Q406 D-3
Q407 E-1
Q410 D-1
Q411 D-1
Q412 E-4
Q413 E-4
Q414 C-2
Q415 B-1
Q416 H-2
Q420 F-1
Q421 F-3
Q501 H-4
Q502 H-4
Q503 H-5
Q504 B-2
Q506 B-3
Q508 G-5
Q509 G-5
Q510 G-5
Q511 B-4
Q512 B-3
Q513 B-3
Q514 B-2
Q515 B-2
TRANSISTOR
Q516 C-3
Q517 B-3
Q518 F-4
Q519 F-4
Q520 B-3
Q521 H-4
Q522 H-5
Q524 G-4
Q525 B-2
Q527 F-5
Q528 B-3
Q530 F-5
Q531 F-5
Q532 G-5
Q535 H-5
Q537 G-5
Q540 G-4
Q541 G-4
Q542 F-5
Q543 G-4
Q544 G-5
Q545 F-4
Q546 G-5
Q547 H-4
Q550 H-5
Q551 H-5
Q552 H-5
Q553 G-6
Q554 G-6
TP
IC406 D-2
IC409 C-3
IC504 B-4
IC511 C-5
IC512 D-6
Q406 E-3
Q410 G-1
Q412 D-4
Q413 E-4
Q414 G-2
Q415 H-1
Q527 D-5
Q531 D-5
Parts Location
P-BOARD (COMPONENT SIDE)
IC
TRANSISTOR
P
TH-37PW7BX
38
