13.16. GK-Board Schematic Diagram
D
3 786
E
B
A
5
F
21
C
4
GK-BOARD TNPA3577
GK-Board Schematic Diagram
9
TX-51P950M/X, TX-43P950M/X
TX-51P950M/X, TX-43P950M/X GK-Board Schematic Diagram
TX-51P950M / TX-51P950X / TX-43P950M / TX-43P950X
74
