MG5000+ / MG5050+ Installation Guide
5
Introduction
Features
• 32 zones (any of which can be wireless or keypad zones)
• 32 users and 32 remote controls (one per user)
• In-field upgradeable
• Menu-driven programming for the Installer, Master, and Maintenance codes. This enables you to program the panel through a simple and easy to use
interface, without the use of section numbers
• Multiple telephone numbers for event reporting: Three for the monitoring station, five for personal dialing
• Calendar with daylight savings time
• Sleep arming method: Similar to Stay arming, Sleep arming allows users to remain in a protected area, but provides a higher level of protection
• Connect up to 15 hardwired keypads on the 4-wire communication bus
• Push button power reset
• Available in 433MHz or 868MHz
• RF jamming supervision (section [700], option [5]): The control panel will report a trouble if the RF signal is being jammed
• Supports SIA reporting format to central station (V4.86 and lower)
MG5050+ Requirements
• PCS265 LTE V4.37 and higher
• IP150+ V5.45 and higher
System Overview
Modules Current Consumption List
Module Description Maximum number per system
K10V/H, K32+,K32LCD+, K32LX, K35, K636,
TM50, TM70
10 and 32-Zone Hardwired LED and LCD Keypad Module,
Touchscreen
15 total including ZX8 / ZX82
ZX8, ZX8SP, ZX82 8-Zone Expansion Module 3
RPT1 Magellan Wireless Repeater Module 2
VDMP3 Plug-In Voice Dialer 1
IP150+ IP Internet Module 1
PCS250/PCS250G, PCS265LTE Communicator Module 1
RX1 Wireless Receiver Module 1
PGM4 4-Output Expansion Module 1
PGM82 8-Output Expansion Module 1
HUB2 2-Port HUB and Bus Isolator 1
PS25/PS45 Power supply 1
HD78F/HD88 IP Camera / Detector 15
Module Current Consumption Module Current Consumption
K10V/H Min. = 44 mA / Max. = 72 mA RPT1 65 mA
K32+ Min. = 49 mA / Max. = 148 mA VDMP3 Min. = 28 mA / Max. = 28 mA
K32LCD+ Min. = 43 mA / Max. = 86 mA IP150+ 100 mA
K32LX 120 mA PCS250 Standby:100 mA / Alarm: 450 mA
K35 Min. = 30 mA / Max. = 70 mA PCS250G Standby:100 mA / Alarm: 450 mA
K636 Min. = 15 mA / Max. = 30 mA PCS265LTE Standby: 60 mA / Max. = 300 mA
TM50 150 mA max + 80 mA sounder RX1 25 mA
TM70 250 mA max + 80 mA sounder PGM4 Min. = 13 mA / Max. = 150 mA
ZX8 Min. = 29 mA / Max. = 31 mA PGM82 315 mA (all PGMs activated)
ZX8SP 28 mA HUB2 Min. = 24 mA / Max. = 50 mA
ZX82 95 mA max (all LED on) HD88
350 mA - IR illumination ON
250 mA - IR illumination OFF
100 mA - System lost AC / Battery operation
HD78F
350 mA - IR illumination ON
250 mA - IR illumination OFF
100 mA - System lost AC / Battery operation
