6
MG5000+ / MG5050+ Installation Guide
Specifications
All control panel outputs are rated to operate between 10.8Vdc and 12.1 Vdc
MG5000+ / MG5050+
Power rating 16.5 VAC (50 or 60Hz) minimum 20 VA (40 VA recommended)
Power consumption MG5000+: 1.2A(Max.), 85 mA (Idle) MG5050+: 1.2A(Max.), 95 mA (Idle)
Aux. power * 0.7A typical, 0.8A maximum, active shutdown at 1.1A
Battery 12 VDC, 4 Ah/7Ah
Battery charging current 500 mA
On-board zones
MG5000+: 2
MG5050+: 5
Bell output ** 1A (fuseless shutdown at 3A)
On-board PGMs
MG5000+: 2
MG5050+: 4 (1+/- trigger)
All on-board PGMS are 100 mA low-current outputs
Dimensions
MG5000+: 14 x 10.4 cm (5.5 x 4.1 in.)
MG5050+: 19 x 10.2 cm (7.5 x 4 in.)
Weight 18g
Operating temperature 0°C to 50°C (32°F to 122°F)
Humidity 5% - 90%
Standards TBD
* Cannot exceed 200 mA for UL installations
** Cannot exceed 1A for UL installations
30 hrs backup 60 hrs backup Recharge to 80% (@350 mA)
7 AHr 150 mA 50 mA 20 hrs.
